Ala Mahlak logo

Ala Mahlak

على مهلك

Real-time AI-powered driver monitoring for safer trips and smarter fleet operations.

Flutter React .NET Django OpenCV YOLOv8

Overview • Architecture • Repositories • Features • Tech Stack • Getting Started • Project Context

Overview

Ala Mahlak is a multi-repository driver-safety platform designed around camera-based driver monitoring, trip management, company administration, and fleet visibility.

The project brings together four main components:

Component Audience Primary responsibility
Mobile app Drivers Ride planning, trip lifecycle, camera-based monitoring, trip history, profile workflows
Web dashboard Companies and admins Fleet overview, driver management, trip monitoring, alerts, support, company profile workflows
Backend API Apps and services Authentication, companies, users, trips, chat, reports, static files, shared contracts
AI service Mobile/backend clients Image-based drowsiness and distraction analysis with computer vision

Note

This repository is the GitHub organization profile. Runtime instructions, API details, and implementation notes live in the component repositories linked below.

Why Ala Mahlak Exists

Road safety depends on human attention, but fatigue and distraction are difficult to detect from trip records alone. Ala Mahlak approaches the problem as a connected software system rather than a single isolated model.

The system combines:

Need Ala Mahlak approach
Driver-facing monitoring A Flutter mobile app with camera, location, trip, map, and profile flows
AI-based driver analysis A Django REST Framework service using facial landmarks, head pose, drowsiness scoring, YOLOv8 object detection, and signal fusion
Fleet administration A React/Vite dashboard for companies, admins, drivers, trips, alerts, support, and reporting
Application backend An ASP.NET Core API with JWT auth, role-based access, company workflows, trip lifecycle, reports, and SignalR chat

The name Ala Mahlak means "take it easy" or "slow down", which matches the project goal: give drivers and fleet operators better visibility before unsafe driving becomes an incident.

Architecture

                                      +-----------------------------+
                                      |        AI Service            |
                                      |  Django REST Framework       |
                                      |  MediaPipe + OpenCV + YOLOv8 |
                                      +--------------+--------------+
                                                     ^
                                                     |
                         uploaded frame / image      | analysis result
                                                     |
+-----------------------------+          +-----------+-------------+          +-----------------------------+
|        Mobile App           |          |       Backend API       |          |       Web Dashboard         |
|  Flutter                    |          |  ASP.NET Core           |          |  React + TypeScript + Vite  |
|  Camera, rides, maps, auth  +--------->|  Auth, companies, trips +<---------+  Fleet, drivers, alerts     |
|  profile, trip history      |          |  chat, reports, files   |          |  support, profiles          |
+-----------------------------+          +-----------+-------------+          +-----------------------------+
                                                     |
                                                     v
                                      +-----------------------------+
                                      |       SQL Server            |
                                      |  Users, companies, trips,   |
                                      |  chat, reports, relations   |
                                      +-----------------------------+

Main Data Flows

Flow Source Destination What happens
Authentication Mobile app / web dashboard Backend API Users and companies register, verify email, log in, refresh sessions, and update profiles
Company membership Mobile app / web dashboard Backend API Drivers search companies, submit join requests, and admins approve or reject membership
Trip lifecycle Mobile app Backend API Drivers start trips, end trips, update highest speed, and review trip history
Driver monitoring Mobile app camera AI service Captured frames are analyzed for drowsiness and distraction signals
Fleet monitoring Web dashboard Backend API Company/admin users review drivers, trips, reports, and alert-oriented screens
Support and chat Mobile/web clients Backend API + SignalR Users and admins exchange messages through REST endpoints and realtime hub support
Reporting Web dashboard Backend API Company/admin users can request PDF driver reports

Repositories

Repository Layer What it contains
Ala-Mahlak-Flutter Mobile app Flutter application under gradprojct/ with auth, onboarding, map/routing flows, camera-based ride monitoring, trip history, chat/profile screens, and Android/iOS projects.
Ala-Mahlak-Frontend Web dashboard React 19 + TypeScript + Vite dashboard with company auth, dashboards, drivers, companies, trip monitoring, alerts, assignment, support, and profile pages.
Ala-Mahlak-Backend Backend API ASP.NET Core solution with API, Core, Infrastructure, Service, and Shared projects for auth, companies, trips, chat, reports, JWT, EF Core, SQL Server, and SignalR.
Ala-Mahlak-AI AI service Django REST Framework API for driver-image analysis using MediaPipe FaceMesh, OpenCV head-pose estimation, drowsiness scoring, YOLOv8 object detection, preprocessing, and fusion logic.

Repository Map

Ala-Mahlak/
|-- .github/
|   `-- profile/README.md                # Organization profile shown on GitHub
|-- Ala-Mahlak-Flutter/
|   `-- gradprojct/                      # Flutter mobile application
|-- Ala-Mahlak-Frontend/                 # React/Vite company dashboard
|-- Ala-Mahlak-Backend/                  # ASP.NET Core backend solution
`-- Ala-Mahlak-AI/                       # Django computer-vision API

Features

Platform Capabilities

Capability Mobile app Web dashboard Backend API AI service
Driver registration/login Yes No Yes No
Company registration/login No Yes Yes No
Email verification/password reset Yes Yes Yes No
Company search and join requests Yes Yes Yes No
Driver and admin management No Yes Yes No
Trip start/end/history Yes Yes Yes No
Highest-speed update Yes No Yes No
Driver monitoring frames Yes No No Yes
Drowsiness analysis No No No Yes
Distraction analysis No No No Yes
Chat and support flows Yes Yes Yes No
PDF driver reports No Yes Yes No
Swagger/OpenAPI documentation No No Yes Yes

Driver Experience

The Flutter app is the driver-facing entry point. Evidence in the mobile repository shows support for:

Area Details
Authentication Registration, login, email verification, profile completion, token persistence
Navigation go_router routing and a main app shell with Home, Search, New Ride, Chat, and Profile tabs
Maps and routing LocationIQ search, reverse geocoding, map tiles, current location, route distance calculation
Trips Ride start/end API calls and previous trip history display
Monitoring Front-camera capture that periodically uploads frames to a distraction-analysis endpoint
Device features Camera, image picker, location permissions, Android and iOS platform projects

Fleet And Admin Experience

The web dashboard is the company/admin-facing interface. Evidence in the frontend repository shows support for:

Area Details
Authentication Company login, registration, forgot-password, OTP reset, protected routes
Dashboard Fleet KPIs, recent distraction alerts, active driver summaries
Companies Admin list, create/promote/downgrade/remove admins, company reports
Drivers API-backed company driver lists, search, filters, detail pages
Trips Company trips and trip monitoring views
Alerts Phone usage, drowsiness, looking away, eating/drinking review screens backed by local mock data
Assignment Company-code sharing and pending join-request decisions
Support Mock live chat and tickets through React Query cache updates
Profile Local profile edits and API-backed company logo upload/removal

Note

The frontend currently mixes API-backed screens with mock data from src/data/mockData.ts. The component README identifies which areas are mocked and which call the backend.

Backend Capabilities

The backend is an ASP.NET Core API organized as a multi-project solution:

Project Responsibility
AlaMahlak.API ASP.NET Core host, controllers, SignalR hub, static files, Swagger
AlaMahlak.Core Domain entities, EF Core entity configurations, repository interfaces
AlaMahlak.Infrastructure EF Core DbContext, generic repository, unit of work
AlaMahlak.Service Application services for auth, companies, trips, chat, and email
AlaMahlak.Shared Request/response contracts, settings models, error responses, error codes

Key backend areas include:

Area Evidence-backed functionality
Auth Register, login, logout, email verification, profile update, password reset
Companies Company registration/login, lookup, join requests, members, admins, logos, reports
Trips Current-user trips, start trip, end active trip, update highest speed
Chat Contacts, conversations, messages, SignalR broadcasts
Files Static file serving for uploaded profile/company images and logo assets
Reports PDF driver report generation through QuestPDF

AI And Computer Vision

The AI service analyzes uploaded driver images and returns structured drowsiness/distraction results.

Pipeline stage Implementation evidence
API layer Django 4.2, Django REST Framework, multipart uploads, drf-spectacular docs
Image validation JPEG, JPG, PNG, BMP, WebP support with upload-size checks
Preprocessing CLAHE, dynamic gamma correction, gray-world white balance, conditional denoising
Face landmarks MediaPipe FaceMesh landmark extraction
Eye/mouth metrics EAR and MAR calculations for drowsiness/yawning signals
Head pose OpenCV solvePnP pitch, yaw, roll estimation
Gaze Horizontal and vertical gaze estimation
Object detection Ultralytics YOLOv8 for COCO phone, drink, and food-related classes
Fusion Rule-based signal fusion into safe/drowsy/distracted classes
Tests pytest and pytest-django coverage for API, drowsiness, FaceMesh, fusion, pose, and YOLO degraded mode

Important

The AI REST API analyzes one uploaded image per request. Temporal behavior such as PERCLOS, blink rate, state debounce, and camera-offset calibration is implemented in the webcam demo rather than the stateless REST endpoint.

Tech Stack

Technology Matrix

Layer Main technologies Supporting packages/tools
Mobile Flutter, Dart go_router, flutter_bloc, dio, http, camera, image_picker, shared_preferences, geolocator, flutter_map, LocationIQ
Web React 19, TypeScript, Vite Tailwind CSS 4, Material UI, TanStack Query, React Router, Framer Motion, Lucide React, ESLint
Backend .NET 10, ASP.NET Core, C# EF Core 10, SQL Server, JWT Bearer auth, SignalR, MailKit, MimeKit, BCrypt.Net, QuestPDF, Swashbuckle
AI service Python, Django 4.2, Django REST Framework MediaPipe, OpenCV, NumPy, Pydantic v2, Ultralytics YOLOv8, drf-spectacular, Gunicorn, WhiteNoise
Testing pytest, pytest-django, Flutter test dependencies, ESLint Backend currently documents build verification rather than a checked-in test project
Deployment evidence Azure Container Apps workflow for AI, live hosted backend Swagger Dockerfile for AI service, Gunicorn, Azure Container Registry workflow

Runtime And Tooling Snapshot

Repository Runtime/tooling evidence
Ala-Mahlak-Flutter Dart SDK constraint ^3.10.8, Android/iOS projects, flutter_lints, flutter_launcher_icons
Ala-Mahlak-Frontend Vite 6, TypeScript 5.8, React 19, ESLint 9, Tailwind CSS 4
Ala-Mahlak-Backend Target framework net10.0, SQL Server through EF Core, Swagger enabled
Ala-Mahlak-AI Python 3.11 Docker image, Django 4.2, DRF, OpenCV/MediaPipe runtime dependencies

API Surface

Backend API Summary

The backend README documents these endpoint groups:

Group Example endpoints Purpose
Auth POST /api/auth/register, POST /api/auth/login, GET /api/auth/me User/company registration, login, profile, verification, password reset
Companies GET /api/companies, POST /api/companies/join-requests, PUT /api/companies/logo Company lookup, membership, admins, drivers, logo, reports
Trips GET /api/trips/me, POST /api/trips/start, POST /api/trips/end User trip lifecycle and highest-speed tracking
Chat GET /api/chat/contacts, POST /api/chat/messages Contacts, conversations, messages
Realtime /hubs/chat SignalR chat hub with JWT support through access_token query string
Health GET /api/health Public backend health check

Live backend Swagger documentation is available at:

https://ala-mahlak.runasp.net/swagger/index.html

AI Service API Summary

Method Path Description
GET / Redirects to /api/docs
GET /api/docs Swagger UI
GET /api/schema OpenAPI schema generated by drf-spectacular
GET /api/v1/health Health check with service version and YOLO status
POST /api/v1/analyze Full driver image analysis response
POST /api/v1/analyze/simple Compact analysis response for lightweight clients

Example AI request:

curl -X POST "http://localhost:8000/api/v1/analyze" \
  -H "accept: application/json" \
  -F "file=@driver_photo.jpg"

The full AI response includes driver state, distraction status, drowsiness score, raw EAR/MAR/head-pose metrics, detected objects, status, timing, explanation, and optional errors.

Getting Started

This organization contains separate applications. Choose the component you want to run first.

Run The Mobile App

git clone https://github.com/Ala-Mahlak/Ala-Mahlak-Flutter.git
cd Ala-Mahlak-Flutter/gradprojct
flutter pub get
flutter run

Warning

The Flutter app currently stores service URLs, a LocationIQ key, and a distraction-analysis CSRF token directly in source files. Rotate exposed credentials if needed and move production secrets out of the app before release.

Run The Web Dashboard

git clone https://github.com/Ala-Mahlak/Ala-Mahlak-Frontend.git
cd Ala-Mahlak-Frontend
npm install
npm run dev

The Vite dev server proxies /api/* requests to the hosted backend URL configured in vite.config.ts.

Run The Backend API

git clone https://github.com/Ala-Mahlak/Ala-Mahlak-Backend.git
cd Ala-Mahlak-Backend
dotnet restore AlaMahlak.sln
dotnet run --project AlaMahlak.API

The backend repository does not include appsettings*.json. Provide configuration through user secrets, environment variables, or another ASP.NET Core configuration provider.

Minimum configuration areas:

Area Example setting
SQL Server ConnectionStrings__DefaultConnection
JWT JwtOptions__SecretKey, JwtOptions__Issuer, JwtOptions__Audience
SMTP SmtpSettings__Host, SmtpSettings__Username, SmtpSettings__Password
App URL AppSettings__ApiBaseUrl

Run The AI Service

git clone https://github.com/Ala-Mahlak/Ala-Mahlak-AI.git
cd Ala-Mahlak-AI
python -m venv .venv
source .venv/bin/activate
python -m pip install --upgrade pip
pip install -r requirements.txt
cp .env.example .env
python manage.py migrate
python manage.py runserver 0.0.0.0:8000

Open the local AI docs at:

http://localhost:8000/api/docs

Configuration Notes

Repository Configuration model
Mobile Service endpoints and API keys are currently hard-coded in Dart source files
Frontend API requests use BASE_URL = '/api'; dev proxy targets the hosted backend
Backend ASP.NET Core configuration sections for connection strings, JWT, SMTP, and app settings
AI .env.example and .env.azure.example cover Django, CORS/CSRF, YOLO, upload size, and Azure settings

Deployment Notes

Repository Evidence-backed deployment state
Mobile Android and iOS platform projects are present; build commands are documented in the component README
Frontend Vite production build is available through npm run build; production must serve or proxy /api correctly
Backend Live Swagger is available; no Docker or deployment manifests are checked in
AI Dockerfile and GitHub Actions workflow exist for Azure Container Registry and Azure Container Apps deployment

AI container summary:

Detail Value
Base image python:3.11-slim
Server Gunicorn with dms.wsgi:application
Port 8000
Health check /api/v1/health
Production dependencies requirements-azure.txt, opencv-python-headless, Gunicorn, WhiteNoise

Quality And Verification

Repository Current verification path
Mobile flutter analyze, flutter test, flutter build apk, flutter build ios are documented; existing widget test is still the default counter test
Frontend npm run build, npm run lint, npm run preview; no test script is configured
Backend dotnet build AlaMahlak.sln; no checked-in test project is present
AI pytest tests/ -v covers API behavior, drowsiness, FaceMesh, fusion, pose estimation, and YOLO degraded mode

Tip

For the fastest end-to-end orientation, read the component READMEs in this order: backend, AI service, mobile app, frontend dashboard. That order explains the APIs before the clients that consume them.

Security And Privacy Notes

Topic Current repository evidence
Authentication Backend uses JWT bearer authentication and role-based authorization
Password handling Backend uses BCrypt.Net for password hashing
Email workflows Backend uses SMTP settings with MailKit/MimeKit for verification and password reset
Secrets Backend and AI document environment/configuration values; Flutter currently includes hard-coded service configuration
File uploads Backend serves uploaded profile/company images; AI validates image type and upload size
CORS/CSRF AI service exposes CORS and CSRF environment variables
Production caution Do not commit real database strings, JWT signing keys, SMTP credentials, API keys, or service tokens

Project Structure By Layer

Mobile App

Ala-Mahlak-Flutter/
`-- gradprojct/
    |-- android/              # Android platform project and permissions
    |-- animation/            # Lottie animation assets
    |-- images/               # Logo, onboarding, auth, map, chat, profile, UI assets
    |-- ios/                  # iOS platform project and permission descriptions
    |-- lib/
    |   |-- core/             # API clients, routing, local storage, services, themes
    |   `-- features/         # Auth, intro, splash, main tabs, map, rides, chat, profile
    |-- test/                 # Flutter widget tests
    `-- pubspec.yaml          # Dependencies, assets, launcher icon config

Web Dashboard

Ala-Mahlak-Frontend/
|-- src/
|   |-- assets/               # Logo animations and local SVG assets
|   |-- components/           # Shared app shell components
|   |-- context/              # Auth context and session state
|   |-- data/                 # Mock dashboard, alert, trip, support, driver data
|   |-- hooks/                # React Query data hooks
|   |-- pages/                # Route-level pages
|   `-- services/             # Backend API client and session helpers
|-- package.json              # Scripts and dependencies
`-- vite.config.ts            # Vite plugins and dev API proxy

Backend API

Ala-Mahlak-Backend/
|-- AlaMahlak.sln
|-- AlaMahlak.API/            # ASP.NET Core host, controllers, SignalR hub, static files
|-- AlaMahlak.Core/           # Domain entities, EF Core configs, repository interfaces
|-- AlaMahlak.Infrastructure/ # EF Core DbContext, repositories, unit of work
|-- AlaMahlak.Service/        # Auth, companies, trips, chat, email services
`-- AlaMahlak.Shared/         # Contracts, settings models, error responses/codes

AI Service

Ala-Mahlak-AI/
|-- api/
|   |-- core/                 # MediaPipe singleton, YOLO wrapper, fusion engine
|   |-- schemas/              # Pydantic response models and enums
|   |-- services/             # DriverMonitorService orchestration pipeline
|   |-- utils/                # Image decoding, validation, conversion
|   |-- vision/               # FaceMesh, head pose, drowsiness analysis
|   |-- config.py             # Thresholds, model paths, runtime settings
|   `-- views.py              # Health and analyze views
|-- dms/                      # Django settings, URLs, ASGI, WSGI
|-- tests/                    # pytest and pytest-django tests
|-- Dockerfile
|-- openapi.yaml
|-- requirements.txt
`-- webcam_demo.py

User Journeys

Driver Journey

Step System behavior
1 Driver creates an account or logs in from the Flutter app
2 Driver completes profile and stores session tokens locally
3 Driver searches/selects route information through map and LocationIQ flows
4 Driver starts a trip through the backend API
5 Mobile app uses front-camera monitoring during the ride
6 Captured frames are sent to the AI analysis endpoint
7 Trip can be ended and previous trip details can be reviewed

Company/Admin Journey

Step System behavior
1 Company user registers/logs in from the web dashboard
2 Company reviews dashboard KPIs and active driver summaries
3 Company handles pending driver join requests
4 Company manages admins and drivers through backend API-backed pages
5 Company reviews trips, alerts, reports, and profile/logo settings
6 Company/admin uses support and chat workflows where implemented

AI Analysis Journey

Step System behavior
1 Client uploads a driver image as multipart form data
2 API validates content type, file presence, and upload size
3 Image is decoded and preprocessed for lighting and noise conditions
4 FaceMesh extracts landmarks for eyes, mouth, gaze, and head pose inputs
5 YOLOv8 detects relevant objects such as phone, drink, and food classes
6 Drowsiness and distraction signals are fused into a driver state
7 API returns structured JSON with confidence, explanation, metrics, and status

Current Gaps And Known Risks

Area Current state
Mobile secrets Some service URLs, keys, and tokens are committed in Flutter source files
Frontend tests No test script is configured in package.json
Frontend mock data Several dashboard/support/alert areas use local mock data
Backend configuration appsettings*.json is not checked in, so setup requires external configuration
Backend migrations/tests No EF migrations or test projects are currently present in the backend solution
AI API temporal context REST endpoint is stateless; temporal logic is in webcam_demo.py
AI OpenAPI snapshot Checked-in OpenAPI and live Django routes should be kept in sync as endpoints evolve

Project Context

This organization represents a graduation-project style platform built around a practical road-safety idea: use widely available software and smartphone capabilities to make driver monitoring more accessible.

Academic project metadata preserved from the original organization profile:

Item Details
Project Ala Mahlak - real-time AI-powered driver monitoring system
Institution context Faculty of Computers and Artificial Intelligence
Academic year 2025 / 2026
Timeline September 2025 to May 2026
Core disciplines Mobile development, frontend development, backend development, AI/computer vision

Project Timeline

Sep 2025                                                        May 2026
   |                                                              |
   |  Planning      Design        Backend       Integration       |
   |  and           and           and API       and testing        |
   |  requirements  architecture  development   across apps        |
   |      |            |              |              |             |
   +------+------------+--------------+--------------+-------------+
          |                           |
          |                           +-- Mobile and web development
          |
          +-- AI model, preprocessing, detection, and API work

Team

Member Role Focus area
Haneen Hassan El-Sayed Mobile Developer Flutter app, UI/UX, camera integration, cross-platform flows
Abdulrahman Ehab Taha Frontend Developer React dashboard, responsive interface, dashboard workflows
Shehab Mohamed Kamal Backend Developer .NET API, server-side logic, database integration
Omar Khalid Saber Backend Developer API development, performance, secure communication
Abdulrahman Eldeeb AI Developer Model architecture, training, deployment-oriented AI work
Shehab Yasser Ali AI Developer Data preprocessing, model evaluation, inference optimization

Supervisors:

Supervisor
Dr. Mary Monir
Eng. Malak Ahmed
Eng. Khaled Ahmed

Quick Links

Resource Link
Mobile app repository https://github.com/Ala-Mahlak/Ala-Mahlak-Flutter
Web dashboard repository https://github.com/Ala-Mahlak/Ala-Mahlak-Frontend
Backend API repository https://github.com/Ala-Mahlak/Ala-Mahlak-Backend
AI service repository https://github.com/Ala-Mahlak/Ala-Mahlak-AI
Live backend Swagger https://ala-mahlak.runasp.net/swagger/index.html

Ala Mahlak - because every driver deserves to arrive safely.

Popular repositories Loading

  1. .github .github Public

Repositories

Showing 1 of 1 repositories

Top languages

Loading…

Most used topics

Loading…
