Wireless RS-485 / USB / TCP / WebSocket bridge
interfaceNode is Atkin Engineering's wireless RS-485 bridge. It bridges USB CDC, RS-485, TCP sockets, and WebSockets - data arriving on any one interface is forwarded to the other three, live, with no PC or gateway software in between.
With Protocol aware set to Dynet, traffic is validated as complete DyNet 1/DyNet 2 frames (check-summed, re-synchronised on invalid data) before being forwarded. Set to None, bytes pass through verbatim with no validation, for any other RS-485-based protocol.
The device is configured entirely through its own web interface - no companion app or desktop software required.
- Bridge: USB CDC ↔ RS-485 ↔ TCP (up to 5 clients) ↔ WebSocket (up to 5 clients), DyNet-aware or raw passthrough
- WebSocket DyNet filtering: choose which DyNet 1 / DyNet 2 opcodes reach WebSocket clients, from the web interface; sensible defaults are built in, and the page shows when a list differs from its default with a one-click
Use default - Web configuration UI: HTTPS, login required, JSON-based
/configAPI, reachable only in configuration mode (mutually exclusive with normal bridge operation); a green, amber or red page border shows whether every service is secured, has a login only, or is open - Security: see Security - unique password per device, login and TLS on every network interface, per-device certificate authority, encrypted settings, security event log
- WiFi: Access Point or Station mode, including WPA2/WPA3-Enterprise (EAP, with EAP-FAST and uploadable RADIUS/CA certificate)
- System log: recent log output, colour-coded by severity, viewable at
/systemlog.htmlin configuration mode - a 128KB in-memory buffer that survives a normal reboot and clears only on a genuine cold boot or a fresh firmware update. Entries carry the date and time once a user has logged in (the web page sets the device clock from the computer). Security events are marked[security] - Watchdog: the device restarts itself if a data task stops responding
- DyNet discovery beacon: independent UDP responder (port 9998), separate from the bridge
- Status LEDs: per-interface RGB (RS485, WiFi), a system-mode status LED (starting / config / AP / STA), LEDC-driven with configurable colour sequences
- OTA firmware updates via the web UI, with automatic rollback if the new firmware fails to start
- IPv4 + IPv6 dual-stack
| Interface | Notes |
|---|---|
| USB CDC | Direct USB CDC, no separate USB-serial driver required |
| RS-485 | Full or half duplex, set via a hardware jumper |
| TCP | Up to 5 simultaneous clients, port configurable in the web UI; TLS and login (AUTH user:pass) on by default |
| WebSocket | /ws, up to 5 simultaneous clients, its own dedicated server separate from the config UI; WSS and login on by default - see Network Services |
Every interface is bridged the same way - a frame received on any one is forwarded to every other, never back out the interface it arrived on.
Firmware releases are published through GitHub Releases.
Each release contains:
- Firmware
.bin - SHA-256 checksum
- Release changelog
- Software bill of materials (
SBOM.spdx) and vulnerability report (SBOM_report.md) - Supporting documentation, where applicable
The device never connects to the internet and can't tell you when new firmware is available. Use GitHub's Watch → Custom → Releases on this repository to be notified of new releases. Version numbers are major.minor.patch; security fixes are released as patch versions - see Security updates.
To update the firmware, enter configuration mode with a single press of the system button, then open the device's web interface and install the downloaded .bin from the Firmware section. No serial connection or additional software required.
Settings, including WiFi, are kept across firmware updates. A setting added by a new firmware version starts from its default - see the Manual.
The device is configured entirely through its own web interface, only reachable while in configuration mode:
- Entering configuration mode: a short press of the system button reboots the device into it
- Logging in: the web interface requires a login; the default password is unique to each device, in the form
XXXX-XXXX-XXXX(type the dashes), and printed on its label - Trusting the device: download the device CA certificate from the Security section and install it once on each computer - browsers and other software then connect without certificate warnings, even after the device's IP address changes (install steps for Windows, macOS, Linux, iOS and Android are in the Manual)
- Factory reset: holding the button for 2 seconds (or
Factory resetin the web interface) erases all user data - settings, WiFi details, passwords, certificates, the USB drive and the system log - and reboots into configuration mode with the default settings - Every setting available in configuration mode is documented in the Manual
Configuration mode and normal bridge operation are mutually exclusive - the device runs as one or the other, and switching between them requires a reboot.
Alongside the bridge itself, interfaceNode runs several independent network services:
- Web configuration UI -
https://<device>(port 80 redirects to HTTPS), JSON/configAPI, configuration mode only; the device CA certificate is athttps://<device>/tls_cert/ca.crt - TCP bridge - port configurable (49152-65535); TLS and login on by default, each can be turned off for clients that can't use them
- WebSocket bridge (
wss://<device>/wson port 443,ws://on port 80 with TLS off) - a dedicated server, separate from the config UI, available during normal bridge operation. Clients log in athttps://<device>/authfor a one-time token. DyNet 1 and DyNet 2 frames can be filtered by type and by opcode before delivery to WebSocket clients - System log (
/systemlog.html) - configuration mode only - DyNet discovery beacon - UDP responder on port 9998, independent of the bridge
- mDNS - device reachable by hostname (
interfacenodeXXYY.local) on the local network; only running services are advertised, under standard service types that follow their TLS setting -_https/_http,_ssl/_socket(TCP bridge),_wss/_ws(WebSocket bridge) - with their TLS and login settings in TXT records
- DyNet 1 & DyNet 2 - complete frames are checksum-validated and re-synchronised on invalid data before being bridged
- Raw / passthrough -
Protocol awareset toNoneforwards every byte verbatim, for any other RS-485-based protocol
- No shared default password - every device has its own, supplied with it
- Login on every network interface - web interface (session), WebSocket bridge (one-time token) and TCP bridge (login line); repeated wrong passwords lock the login for an increasing time
- Encryption in transit - TLS 1.2 (ECDHE, AES-GCM) for the web interface, WebSocket and TCP bridges, on by default
- Per-device certificate authority - each device makes its own CA and keys (ECDSA P-256) on the device. Install the CA certificate once per computer; the device issues its own certificate for its names and current IP addresses and re-issues it automatically when an address changes. The CA can only vouch for the device's own names and private network addresses. Your own certificate can be uploaded instead
- Encryption at rest - passwords stored only as salted hashes (PBKDF2-HMAC-SHA256); settings storage (NVS) encrypted
- Security event log - logins, lockouts, setting changes, certificate changes, clock corrections, firmware updates, factory resets and restart reasons are recorded on the device with the date and time (never passwords or keys), with an opt-out
- Full factory reset - erases all user data, credentials and the device certificates; a new CA is made on the next start
- Debug interfaces - JTAG disabled in release firmware
- Security updates are provided free of charge for 7 years from each unit's production date - the end date (month and year) is on the product label and box
- Security fixes are released as patch versions (
x.y.Z) as soon as they are ready, separately from feature releases, on the Releases page - Each release includes an SBOM and a vulnerability report checked against the National Vulnerability Database
- Vulnerabilities are acknowledged within 1 week, assessed within 3 weeks and fixed within 8 weeks (3 weeks if actively exploited) - see SECURITY.md
interfaceNode features a physical RS-485 transceiver (duplex mode set via a hardware jumper), USB CDC, and per-interface RGB status LEDs. Full electrical and mechanical specifications are in the Datasheet.
- Manual (
documents) - operation, configuration, every setting available in configuration mode - Datasheet (
documents) - hardware specifications
Each release lists a SHA-256 checksum alongside its .bin. To verify a download before flashing it:
# Linux
sha256sum interfaceNode.bin
# macOS
shasum -a 256 interfaceNode.bin
Compare the result against the checksum published on the release page.
For product and general support enquiries, visit www.atkin.engineering or email @ temp-pocket-3g@icloud.com
To report a security vulnerability, do not open a public issue - see SECURITY.md for how to report it directly. Security update commitments are under Security updates.
interfaceNode contains proprietary firmware belonging to Atkin Engineering. The repository and its releases are publicly viewable and downloadable, but no permission is granted to copy, modify, distribute, reverse engineer, or commercially exploit this software except as expressly authorised by Atkin Engineering - see LICENSE for the full terms.
© Copyright 2026 Atkin Engineering. All Rights Reserved. 1
Specifications are subject to change without notice. No representation or warranty as to the accuracy or completeness of the information included herein is given and any liability for any action in reliance thereon is disclaimed.
