[ophirhan]

Summary

When leaving home Wi‑Fi, the Android Relay power-tools WebSocket could stay stuck on a preferred Secure Link route that was no longer reachable. Chat already recovered via Tailscale; Relay did not, because sticky Prefer + hysteresis kept publishing the dead higher-priority endpoint (and VPN/cell onAvailable often cancelled the network-loss path before a sustained-loss demotion). Separately, plain ws:// to a paired Tailscale/LAN candidate was blocked unless insecure mode was enabled, even though ConnectionSecurity already treats those hosts as overlay-encrypted.

This change demotes a preferred active route that stays dead past the existing network-loss grace window and allows trusted-overlay plain WebSocket URLs without the insecure toggle, so Relay can fall through automatically the way chat already does.

Changes

• Schedule an active-route demotion job when re-resolve prefers a lower-priority healthy winner but hysteresis still holds a higher-priority dead activeEndpoint; after the grace window, mark sustained loss and republish the healthier route. Cancel the job on same/higher-priority publish, unregister, or disconnect.
• Allow plain ws:// without insecure mode for loopback, private LAN, Tailscale CGNAT (100.64/10), and MagicDNS (.ts.net); keep blocking public cleartext WebSocket URLs.
• Soften the connection insecure flag when the socket is trusted-overlay plain rather than public cleartext (aligns ConnectionManager with ConnectionSecurity’s overlay model).
• Unit coverage: leave-home demotion in ConnectionManagerRouteTest; trusted-overlay vs public ws:// in ConnectionManagerUrlGuardTest.
• CHANGELOG Unreleased notes for the user-visible failover and overlay plain-socket behavior.

Transport policy note (wss:// vs trusted-overlay plain)

AGENTS.md’s Android “wss:// only” line is the default product posture for public/cleartext internet hops. It is not a claim that overlay-encrypted plain schemes are forbidden:

• ConnectionSecurity.kt already documents that encrypted includes overlay transports (Tailscale/WireGuard / secure proxy): a ws:// link over a tailnet is WireGuard-encrypted end-to-end and must not be labelled insecure; only plain scheme with no overlay warns.
• Pairing already stores LAN/Tailscale Relay candidates as plain ws:// on private/CGNAT hosts in normal Secure Link + tailnet setups; chat HTTP surfaces follow the same overlay model.
• This PR does not open public Internet cleartext: ws://relay.example.com / public unicast still require the existing insecure-mode path.
• The change only stops requiring the Settings insecure toggle for hosts that ConnectionSecurity already treats as overlay-encrypted, so automatic leave-home failover can attach without a manual policy flip.

Maintainer call remains welcome if product wants Secure Link wss:// exclusively even on tailnet (would need paired wss candidates or a different attach path).

Verification

• ./gradlew :app:testSideloadDebugUnitTest --tests com.hermesandroid.relay.network.relay.ConnectionManagerRouteTest --tests com.hermesandroid.relay.network.relay.ConnectionManagerUrlGuardTest — BUILD SUCCESSFUL
• GitHub Actions on this PR head: Android Lint / Build / Test — pass; Required checks — pass.
• On-device dogfood:
  • Device: OnePlus CPH2653
  • OS: Android 16 (API 36)
  • App: Hermes Relay sideload 1.18.1 dogfood build including this change
  • Prefer Secure Link kept; when preferred Secure Link was unreachable off home network, automatic fallthrough attached Relay on the paired Tailscale candidate (clients ≥ 1) without enabling insecure mode or manually flipping Prefer.
  • At-home re-check: Gateway footer shows Encrypted · TLS (not insecure amber) with Relay extensions Ready while Prefer Secure Link is active.
  • Public cleartext ws:// remains blocked without insecure mode (unit coverage).

Screenshots

Hosts redacted. Status proof (Encrypted chip / not insecure amber) and route overview chrome:

Leave-home demotion itself is timing/network behavior (covered by ConnectionManagerRouteTest); the insecure-warning change is primarily the absence of an amber insecure state for trusted-overlay plain sockets (gate + badge alignment), not a new layout.

Compatibility / risk

• Standard Hermes / unmodified upstream hosts: client-only Android change. No plugin/server API changes.
• Security: public Internet plain ws:// still requires insecure mode. Overlay plain is limited to loopback/private/Tailscale hosts aligned with existing ConnectionSecurity overlay model.
• Prefer / Natural order preferences are preserved; demotion only applies when the preferred active route stays unreachable past the grace window.
• Rollout/rollback: client-only; revert restores prior sticky hysteresis and stricter plain-ws:// gate.
• No migrations or stored-schema changes.

Lineage / contributor credit

• Source PR(s): N/A
• Attribution preserved by: N/A

Checklist

• Target branch is dev, unless this is a dev → main release PR or a focused production-tag hotfix PR to main
• Scope is focused and related issues/PRs are linked
• Android changes: lint and focused tests ran, or rationale is listed above
• Translation changes: locale validation/review ran, or N/A is listed above
• Server/plugin changes: focused tests ran, or N/A/rationale is listed above
• Desktop changes: build/tests ran, or N/A/rationale is listed above
• Docs/site changes: build or link/route checks ran, or N/A/rationale is listed above
• UI changes were tested on a relevant device/emulator/desktop surface, or the missing proof is stated above
• Commit messages follow Conventional Commits
• CHANGELOG.md is updated for user-visible changes, or N/A is listed above
• Public writing hygiene checked: no secrets, private infrastructure, personal names, or AI/process narration
• Salvaged/replacement work links source PRs and preserves contributor authorship, or N/A is listed above

[hermes-relay-triage]

🤖 Hermes-Relay automated PR intake

Thanks for tackling Android Relay failover! The PR targets dev and includes all template sections, a focused test command with a reported successful result, an explicit lint omission rationale, on-device recovery notes, compatibility/rollback details, and lineage marked N/A.

Please add the device/Android version used for dogfooding and a screenshot or short recording showing the changed insecure-warning behavior. The stated plain-ws:// exception also needs maintainer confirmation against the repository's documented wss://-only policy. Android CI is still pending; intake does not verify implementation correctness.

A maintainer will review the transport-policy exception, device evidence, and implementation once the checks are available.

[ophirhan]

Intake follow-up

Addressed the automated intake notes:

Device / OS

• OnePlus CPH2653 · Android 16 (API 36)
• Sideload dogfood build 1.18.1 including this PR tip

Screenshot

Redacted device proof (Encrypted status chip / not insecure amber; hosts scrubbed):

wss://-only policy

Default public posture remains TLS/wss://. This PR does not allow public cleartext WebSocket URLs.

It aligns the Relay socket gate with existing ConnectionSecurity overlay semantics: Tailscale/LAN plain is overlay-encrypted and must not be labelled or gated as “insecure,” while public ws:// still requires the insecure-mode path. Full write-up is in the updated PR body (Transport policy note).

CI

Android Lint / Build / Test and Required checks are green on the current head (intake was posted while checks were still pending).

[ophirhan]

Leave-home / Tailscale device proof (follow-up)

Earlier screenshot was taken at home on Secure Link — correct preferred-route behavior, but not the demotion claim.

This capture (Wi‑Fi off):

• Device: OnePlus CPH2653 · Android 16 (API 36) · sideload 1.18.1
• Routes: Current route = Tailscale (HTTP) · Reachable · Gateway Active / online
• Chrome badge: Encrypted (Tailscale)
• Scenario: home Wi‑Fi disabled → preferred Secure Link unreachable → auto path uses Tailscale (no manual Prefer)

Redacted screenshot (IPs blacked out): committed only on side branch chore/pr-evidence-666 as docs/pr-evidence/pr666-tailscale-leave-home-redacted.png — not in this PR’s diff.

Related dogfood hardening (separate PR): #668 — idle/retarget watchdog no longer session.interrupts live model waits (was mislabeled user_stop in host logs).

[ophirhan]

Rebased onto current dev (force-with-lease). Hygiene-scan clean.

Leave-home demotion proof was already on the PR earlier; head is now current with dev. Android checks re-running.

Ready for review when CI is green.

[ophirhan]

@Codename-11 gentle review request when you have a moment — rebased onto current dev, CI addressed on our side. Happy to iterate on anything you want changed.
