APXinf-robo

ApxInf is a reimagined edge inference engine born of the agentic coding era, combining high performance, reliability, and energy efficiency across devices with an evolving agentic workflow that radically simplifies custom model development.

implemented with system language Rust with no other externel dependencies
embodied AI is highest priority, VLA/WAM models on Jetson/DriveOS Thor/Orin
Agentically optimized CUDA Kernels

The first version of ApxInf ships with highly optimized PI-0.5 VLA model on Jetson Thor & Orin devices, and supports BF16, FP8 and INT8 precisions.

APXinf-robo carries ApxInf as a git submodule at apxinf/.

Quick start

Make sure you have ApxInf built and installed, see Build APXinf-robo for instructions.

Quickly benchmarking PI-0.5

Benchmarking PI-0.5 with randomly generated weights.

python scripts/bench_pi05.py --random-weights --precision bf16 --layer l1 \
  --views 2 --token-count 10 --action-horizon 10 --num-flow-steps 10 \
  --warmup 10 --samples 100 --autotune

python scripts/bench_pi05.py --random-weights --precision fp8 --layer l1 \
  --views 2 --token-count 10 --action-horizon 10 --num-flow-steps 10 --autotune

These commands report P50 after 10 warm-up iterations. --samples selects the measurement count (100 in the BF16 example, 30 by default). Synthetic inputs check runtime and latency; use LIBERO evaluation to measure task success.

Run a policy through Python API

import numpy as np
from apxinf_robo import build_robot_policy

policy = build_robot_policy("franka_libero", "<path-to-model>", precision="bf16")

observation = {
    key: np.zeros((256, 256, 3), np.uint8)
    for key in policy.metadata["image_keys"]
}
observation[policy.metadata["prompt_key"]] = "put both moka pots on the stove"
if state_key := policy.metadata.get("state_key"):
    observation[state_key] = np.zeros(policy.metadata["state_dim"], np.float32)

result = policy.infer(observation)

result["actions"]   # (H, policy.action_dim) float32, unnormalized
result["timing"]    # model_ms / total_ms
policy.close()

<path-to-model> is a checkpoint directory (model.safetensors, config.json, and that model's tokenizer/normalizer assets); none ships with this package. Resize, tokenization, normalization, and the flow sampler all run inside infer — pass raw frames.

Serve it with OpenPI compatible websocket server

apxinf-robo serve --robot franka_libero \
  --model-dir <path-to-model> --precision bf16 --port 8000

An unmodified openpi-client connects to it:

from openpi_client import websocket_client_policy

client = websocket_client_policy.WebsocketClientPolicy("127.0.0.1", 8000)
actions = client.infer(observation)["actions"]

Performance

Two views, 224x224 NHWC uint8, 10 flow steps, H=10, batch 1. Latency is steady-state CUDA Graph replay P50.

Hardware	Precision	Latency	Throughput
Jetson AGX Thor	BF16	72.45 ms	13.8 Hz
Jetson AGX Thor	FP8	41.16 ms	24.3 Hz
Jetson AGX Orin	BF16	165.67 ms	6.0 Hz
RTX 4090	BF16	31.38 ms	31.9 Hz
RTX 4090	INT8	25.99 ms	38.5 Hz

With onestep action generation pruning.

Hardware	Precision	Latency	Throughput
Jetson AGX Thor	BF16	44.05 ms	22.7 Hz
Jetson AGX Thor	FP8	26.32 ms	38.0 Hz
Jetson AGX Orin	BF16	119.05 ms	8.4 Hz
RTX 4090	BF16	20.36 ms	49.1 Hz

LIBERO-10, 10 tasks x 50 episodes, H=10, replan=5, seed 7. PI0.5 reference is 92.4%.

Hardware	Precision	Trials	Success	Rate
Jetson AGX Thor	BF16	500	464	92.8%
Jetson AGX Thor	FP8	500	461	92.2%
Jetson AGX Orin	BF16	500	460	92.0%

Port a new model with an agent

apxinf/skills/model-port-workflow drives the whole sequence.

Install it once, from the repository root:

# Claude Code
mkdir -p .claude/skills && ln -s ../../apxinf/skills/model-port-workflow .claude/skills/

# Codex
mkdir -p ~/.agents/skills && ln -s "$(pwd)/apxinf/skills/model-port-workflow" ~/.agents/skills/

Then invoke it with the model, the target, and the acceptance bar:

/model-port-workflow port GR00T N1.7 from <path-to-reference-implementation> to
ApxInf, Jetson Thor, BF16, parity against the reference within 1e-2

The workflow follows these guides to implement and validate the model port:

Build APXinf-robo

git clone --recursive https://github.com/RLinf/APXinf-robo.git
cd APXinf-robo
python3 -m venv .venv && source .venv/bin/activate
pip install maturin
CARGO_TARGET_DIR=target/wheel maturin build --release --features cuda --auditwheel skip -m apxinf/crates/apxinf-py/Cargo.toml
pip install --force-reinstall target/wheel/wheels/apxinf_py-*.whl
pip install -e "./apxinf/python/apxinf[serving]" --config-settings editable_mode=strict
pip install -e ".[libero,serve]"

Install on Linux with an NVIDIA driver, CUDA toolkit, Rust, and cmake. Use --features cuda when building the binding. The serving extra installs msgpack and websockets; omit it for in-process use. Strict editable installation picks up edits to existing engine Python files without reinstalling. Reinstall after adding modules or changing dependencies, and keep its generated apxinf/python/apxinf/build/__editable__.* directory.

The build queries the visible GPU for its compute capability and compiles the kernels for exactly that architecture, so build on the machine you deploy to; cross-compiling fails unless APXINF_CUDA_ARCH names the target (sm_87 Orin, sm_101 Thor-U, sm_110 Thor).

Check the compiled extension, the Robo package, and GPU inference:

python -c 'import apxinf_py; print(apxinf_py.__version__)'
python -c 'import apxinf_robo; print(apxinf_robo.__version__)'
python scripts/bench_pi05.py --random-weights --precision bf16 --layer l1 --samples 5

Both imports must succeed and the benchmark must complete with latency results. If nvcc --version, cargo --version, or cmake --version fails, install:

NVIDIA build environment
Rust toolchain
cmake (apt install cmake)

Using APXinf-robo from Python

Use build_robot_policy for a named robot. Choose another entry point when your application supplies its own processing or needs a network service.

Entry point	Input	Output
`build_robot_policy`	Robot preset, checkpoint, raw observations	Robot actions
`load_policy`	Checkpoint, input field names, raw observations	Policy actions
`load_bare_model`	Preprocessed images, tokens, noise	Normalized model actions
`websocket_server`	A policy and listening address	OpenPI-compatible service

L1 — bare model

You own resize, tokenization, noise, and unnormalization; the model takes already-resized frames and returns a normalized-domain chunk.

from apxinf_robo import load_bare_model

model = load_bare_model("<path-to-model>", precision="bf16")

# rgb: uint8 [views, H, W, 3] at model.image_size; tokens: uint32; noise: float32
actions = model.infer_rgb(rgb, "nhwc", token_ids, noise)   # (H, action_dim)
model.action_horizon, model.num_views, model.image_size    # what it was loaded for

L2 — policy

Pass raw images, state, and a prompt to build_robot_policy. The selected preset supplies input field names, state processing, and output action width.

from apxinf_robo import build_robot_policy

policy = build_robot_policy(
    "franka_libero", "<path-to-model>",
    precision="bf16",
)

policy.metadata             # robot, robot_slots, image_keys, state_key, action_horizon, ...

result = policy.infer(observation)
result["normalized_actions"]  # what L1 returned, before trim + unnormalize

Each preset field can be overridden per call (image_keys, state_key, prompt_key, action_dim, discrete_state) to match your client. To run a checkpoint without a robot preset, use load_policy:

from apxinf_robo import load_policy

policy = load_policy(
    "<path-to-model>",
    precision="bf16",
    action_dim=None,        # default: infer the model's full vector from checkpoint weights
)

L3 — websocket server

Wraps an L2 policy in the OpenPI wire protocol. See OpenPI-compatible serving.

OpenPI-compatible serving

The server speaks OpenPI's websocket protocol, so an existing openpi-client robot stack connects without a code change — swap the endpoint and keep the observation dict you already send.

from apxinf_robo import build_robot_policy, websocket_server

policy = build_robot_policy("unitree_g1", "<path-to-model>", precision="bf16")
websocket_server(policy, "0.0.0.0", 8000).serve_forever()

Select the preset matching your checkpoint and client with --robot. Match the client's camera fields, state encoding, and action layout to that preset.

Preset	Cameras	State	Action
`franka_libero`	`observation/image`, `observation/wrist_image`	`observation/state`; encoding is checkpoint-specific	7-dim EEF delta
`unitree_g1`	3 views	16-dim, discretized into the prompt	delta joints, 32→16 encode

--help lists every preset. If an installed client uses different keys, pass the input fields through --image-keys / --state-key, or register a preset. See Adding an embodiment.

The server keeps the checkpoint's native action width unless the user supplies --action-dim or selects a preset with a deployable width. It publishes the resolved wire contract in connect-time metadata so the client can assert it rather than guess.

Precisions

BF16

The default, on every supported device. Runs on the checkpoint alone; no calibration.

apxinf-robo serve --robot franka_libero \
  --model-dir <path-to-model> --precision bf16 \
  --port 8000

policy = build_robot_policy("franka_libero", "<path-to-model>", precision="bf16")

FP8

Thor only, where it is the fastest path. Orin has no FP8 Tensor Cores and is not supported.

FP8 needs per-tensor activation scales. Pass the calibration generated for the deployment data explicitly; when omitted, ApxInf falls back to <path-to-model>/calibration.json:

apxinf-robo serve --robot franka_libero \
  --model-dir <path-to-model> --precision fp8 \
  --calibration <path-to-calibration.json> \
  --port 8000

policy = build_robot_policy(
    "franka_libero", "<path-to-model>",
    precision="fp8",
    calibration="<path-to-calibration.json>",
)

If the checkpoint does not contain calibration.json, generate one from representative Observations:

python3 scripts/calibrate_pi05.py \
  --model-dir <path-to-model> \
  --manifest <path-to-observations.jsonl>

For LIBERO, first capture observations using the robot preset. This step needs LIBERO and MuJoCo, but no model checkpoint:

apxinf-robo capture-libero --robot franka_libero --suite libero_10 \
  --output-dir devlocal/fp8-calibration/observations

The output directory contains one NPZ file per observation. On the calibration machine, read those files with the same input fields:

python scripts/calibrate_pi05.py --model-dir <path-to-model> \
  --image-key observation/image --image-key observation/wrist_image \
  --state-key observation/state --prompt-key prompt \
  --input-dir devlocal/fp8-calibration/observations \
  --output <path-to-model>/calibration.json

For another preset, use the field arguments printed by capture-libero. Keep the NPZ directory to reuse the same inputs in later calibration runs. Successful calibration prints the sample count and output profile path. Pass that profile to serve --precision fp8 --calibration <path-to-model>/calibration.json.

Alternatively, run LIBERO directly on the calibration machine:

python scripts/calibrate_pi05.py --model-dir <path-to-model> \
  --libero-suite libero_10 --output <path-to-model>/calibration.json

This uses the calibrator's default input fields. Override them with --image-key, --state-key, and --prompt-key when needed. For NPZ and manifest formats, see PI0.5 FP8 calibration.

INT8

W8A8, optimized for Orin (SM87) and Ada (SM89). Needs nothing beyond the checkpoint.

apxinf-robo serve --robot franka_libero \
  --model-dir <path-to-model> --precision int8 --port 8000

policy = build_robot_policy("franka_libero", "<path-to-model>", precision="int8")

LIBERO evaluation

Get the checkpoint

The published accuracy is pi05_libero_base, π0.5 fine-tuned on LIBERO — an arbitrary π0.5 checkpoint might not reproduce it.

pip install -U huggingface_hub
hf download lerobot/pi05_libero_base --local-dir <path-to-model>
curl -fL https://storage.googleapis.com/openpi-assets/checkpoints/pi05_libero/assets/physical-intelligence/libero/norm_stats.json \
  -o <path-to-model>/norm_stats.json

The lerobot/pi05_libero_base checkpoint lost its normalization statistics during repository updates. To reproduce the officially reported performance, download OpenPI's LIBERO norm_stats.json separately as shown above and pass it explicitly with --norm-stats.

Run

The rollout needs LIBERO and MuJoCo:

python -c 'from libero.libero import benchmark'

If that fails, install LIBERO from source:

git clone https://github.com/Lifelong-Robot-Learning/LIBERO.git <path-to-libero>
pip install -r <path-to-libero>/requirements.txt   # robosuite brings MuJoCo; pins numpy==1.22.4
pip install -e <path-to-libero>
export MUJOCO_GL=egl                               # headless; osmesa if the machine has no EGL

LIBERO pins NumPy 1.22.4, which is incompatible with Python 3.12. Use a compatible simulator environment; --no-deps does not skip packages explicitly listed in requirements.txt.

--backend websocket additionally needs openpi-client, from an openpi checkout:

git clone https://github.com/Physical-Intelligence/openpi.git <path-to-openpi>
pip install -e <path-to-openpi>/packages/openpi-client

apxinf-robo eval-libero builds the policy in-process — no server involved:

apxinf-robo eval-libero --backend in-process --model-dir <path-to-model> \
  --norm-stats <path-to-model>/norm_stats.json \
  --precision bf16 --action-horizon 10 \
  --suite libero_10 --tasks all --trials-per-task 50 \
  --results-jsonl <out-dir>/results.jsonl --summary-json <out-dir>/summary.json

That is the published protocol: all 10 LIBERO-10 tasks x 50 episodes at seed 7 (the default), 500 episodes in total.

Options

--suite picks the task suite, --tasks a comma list within it, and --trials-per-task the episode count; a smoke run is --tasks 0 --trials-per-task 1.
The model flags — --model-type, --norm-stats, --action-horizon, --action-dim, --discrete-state, FP8 --calibration — belong to --backend in-process alone.
--backend websocket --host <h> --port <p> evaluates a running server instead, on this machine or another. The model flags belong to the server. At connection, the evaluator checks --precision and any published image, state, and prompt field names against franka_libero. A mismatch stops the run; unpublished fields are not checked. Pass --norm-stats <path-to-model>/norm_stats.json to apxinf-robo serve when serving this checkpoint.
Runs are resumable: completed task/trial rows in the JSONL ledger are skipped, and the summary reports success rate alongside per-segment latency.

Benchmark

Measure latency with a checkpoint:

python scripts/bench_pi05.py --model-dir <path-to-model> --precision bf16 \
  --layer l1,l2 --warmup 10 --samples 30 --out devlocal/benchmark/results.json

Layer	Measurement
`l1`	Model inference from resized RGB, including the Python/Rust call
`l2`	Engine policy, including its preprocessing and postprocessing
`l3`	Client-to-server round trip, including the served policy and transport

L2 excludes robot-specific processing added by build_robot_policy. To include that processing, start a server with the required robot preset and measure L3:

python scripts/bench_pi05.py --layer l3 --precision bf16 \
  --host 127.0.0.1 --port 8000 --out devlocal/benchmark/server.json

--random-weights runs without a checkpoint. Use --views, --image-size, --action-horizon, --num-flow-steps, and --token-count to set its workload. Synthetic L2 uses a fixed-length tokenizer and identity normalization.
--action-horizon also overrides a checkpoint's native horizon.
--calibration applies to synthetic FP8 runs; checkpoint runs read calibration.json from the checkpoint directory.
--warmup and --samples default to 10 and 30. The command prints latency statistics; --out also saves JSON. Compare runs with matching layers, precision, input shapes, and sampling settings.

For LIBERO task success and per-segment latency, use LIBERO evaluation.

For one-step evaluation, see Run warm-start with one-step.

NVIDIA build environment

A complete CUDA toolkit is required: nvcc, CUDA headers and runtime, cuBLAS and cuBLASLt development libraries, and NVTX (libnvToolsExt on Jetson, libnvtx3interop on desktop CUDA). Also a C/C++ compiler, linker, ar, Git, pkg-config, and Python 3. The CUDA kernels, CUTLASS, and FlashAttention sources are vendored — no external checkout needed.

Install the driver and toolkit through the JetPack, DRIVE OS, or CUDA distribution for the machine, then check nvcc --version. If CUDA does not live at /usr/local/cuda, point CUDA_PATH at it.

Device	Architecture	Validated toolkit
Jetson AGX Thor	`sm_110`	CUDA 13.0
Thor-U	`sm_101`	CUDA 12.8
Jetson AGX Orin	`sm_87`	CUDA 12.6, 13.2
RTX 4090	`sm_89`	CUDA 12.8

Rust toolchain

curl --proto '=https' --tlsv1.2 -sSf https://sh.rustup.rs | sh
source "$HOME/.cargo/env"
rustup default stable

Built with Rust 1.95 and 1.96; no minimum supported version is declared.

The engine submodule

Initialize or restore the engine version recorded by this checkout:

git submodule update --init --recursive

Record the Robo and engine revisions alongside benchmark or evaluation results:

git rev-parse HEAD
git -C apxinf rev-parse HEAD
git submodule status apxinf

If the output starts with +, the engine is checked out at a different commit from the one recorded by this Robo checkout. Use git submodule update --remote only for a deliberate engine upgrade; it follows main, as configured in .gitmodules. Before submitting an upgrade, review the gitlink diff and run tests/test_parity.py with APXINF_PARITY_CHECKPOINT set to a compatible checkpoint.

Acknowledgement

The development of APXInf has been inspired by, and benefits from, the ideas and tooling of the broader open-source community. In particular, we would like to thank the teams and contributors behind FasterTransformer, TensorRT-LLM, llama.cpp, FlashAttention, FlashRT, vLLM, sgLang, and if we have inadvertently missed your project or contribution, please open an issue or a pull request so we can properly credit you.

License

Apache 2.0. Vendored third-party components retain their own licenses.

Community

Scan the QR Code to join our Wechat Group

Name		Name	Last commit message	Last commit date
apxinf @ ba968f6		apxinf @ ba968f6
configs/rlinf		configs/rlinf
doc		doc
examples		examples
scripts		scripts
src/apxinf_robo		src/apxinf_robo
tests		tests
.gitignore		.gitignore
.gitmodules		.gitmodules
LICENSE		LICENSE
README.md		README.md
pyproject.toml		pyproject.toml

Navigation Menu

Repository files navigation

APXinf-robo

Quick start

Quickly benchmarking PI-0.5

Run a policy through Python API

Serve it with OpenPI compatible websocket server

Performance

Port a new model with an agent

Build APXinf-robo

Using APXinf-robo from Python

L1 — bare model

L2 — policy

L3 — websocket server

OpenPI-compatible serving

Precisions

BF16

FP8

INT8

LIBERO evaluation

Get the checkpoint

Run

Options

Benchmark

NVIDIA build environment

Rust toolchain

The engine submodule

Acknowledgement

License

Community

About

Releases

Packages

Contributors

Languages

Latest commit

History

Folders and files

Repository files navigation

APXinf-robo

Quick start

Quickly benchmarking PI-0.5

Run a policy through Python API

Serve it with OpenPI compatible websocket server

Performance

Port a new model with an agent

Build APXinf-robo

Using APXinf-robo from Python

L1 — bare model

L2 — policy

L3 — websocket server

OpenPI-compatible serving

Precisions

BF16

FP8

INT8

LIBERO evaluation

Get the checkpoint

Run

Options

Benchmark

NVIDIA build environment

Rust toolchain

The engine submodule

Acknowledgement

License

Community

About

Resources

Stars

Watchers

Forks

Releases

Packages

Contributors

Languages
