SafwatX - Network Management App

SafwatX is a robust, cross-platform Flutter application designed for network management and monitoring. It enables users to scan network devices, monitor bandwidth, block/unblock devices using ARP spoofing, and export data for analysis.

Features

• Network Device Scanning: Discover devices with details like IP, MAC, hostname, vendor and blocking status.

• Bandwidth Monitoring: Track download and upload speeds.

• Device Blocking/Unblocking: Restrict network access for specific devices.

• Speed Testing: Measure network performance with integrated speed tests (windows upload speed test not implemented ).

• Data Export: Export device lists to Excel for reporting.

• Cross-Platform Support: Windows and Linux.

Screenshots

Installation

Prerequisites

• Flutter: Install Flutter.
• Git: To clone the repository.
• Platform-Specific Requirements:
  • Windows:
    • WinPcap/Npcap for packet capture. Download winpcap.
    • Admin privileges for ARP spoofing (in developing run editor with Admin privileges ).
    • .exe file
  • Linux:
    • CLI tools: arp-scan, arpspoof, ebtables, iptables, speedtest-cli, dig, arping.
    • libpcap for packet capture.
    • Root privileges for network operations (the linux file in project root already ask for password when run in debug and release).
    • .deb file
• Dependencies: Listed in pubspec.yaml (e.g., provider, excel, path_provider).

Steps

1. Clone the Repository:

   git clone https://github.com/ZiadSafwat/safwatx.git
   cd safwatx

2. Install Flutter Dependencies:

   flutter pub get

3. Set Up Platform-Specific Tools:

   • Windows:
     • Install winpcap if not already present.
   • Linux:
     • Install required tools:

       sudo apt update
       sudo apt install arp-scan dsniff ebtables iptables dnsutils python3-speedtest-cli libpcap-dev

     • Ensure arpspoof and arping (from dsniff) are accessible in the system PATH.
     • No asset setup is needed, as Linux uses system-installed tools.

4. Run the App:

   • Windows (run editor with admin privileges):

     flutter run

   • Linux (the app will ask for root privileges):
     • if you want to package app to debian run this :

       flutter_distributor release --name=SafwatX --jobs=release-SafwatX-linux-deb

     • i have modified the linux\runner\main.cc file to ask for root in debug and release app version:

        //old code
        //#include "my_application.h"
        //
        //int main(int argc, char** argv) {
        //  g_autoptr(MyApplication) app = my_application_new();
        //  return g_application_run(G_APPLICATION(app), argc, argv);
        //}
        // new code
        #include "my_application.h"
        #include <unistd.h>
        #include <stdlib.h>
        #include <sstream>
        #include <iostream>

        int main(int argc, char** argv) {
          if (getuid() != 0) {
            std::cerr << "Not running as root. Attempting to relaunch with pkexec...\n";

            // Rebuild command with GUI env variables
            std::stringstream command;
            command << "pkexec env DISPLAY=$DISPLAY XAUTHORITY=$XAUTHORITY \"" << argv[0] << "\"";
            for (int i = 1; i < argc; ++i) {
              command << " \"" << argv[i] << "\"";
            }

            return system(command.str().c_str());
          }

          g_autoptr(MyApplication) app = my_application_new();
          return g_application_run(G_APPLICATION(app), argc, argv);
        }



Usage

1. Launch the App:

   • On Windows, WinArpSpoof.exe starts automatically to enable network operations.
   • On Linux, the app uses system CLI tools (arp-scan, arpspoof, etc.).
   • The dashboard displays connected devices, bandwidth metrics, and control options.

2. Scan Network:

   • Click "Scan Network" to list devices with IP, MAC, hostname, and blocking status.
   • Your device is marked as "(your Device)" in the list.

3. Monitor Bandwidth:

   • View real-time download and upload speeds per sec, updated every 3 seconds.
   • Windows uses wmic; Linux uses /proc/net/dev.

4. Block/Unblock Devices:

   • Select a device and toggle block/unblock.
   • Windows uses WinArpSpoof.exe block/unblock.
   • Linux uses arpspoof, ebtables, and iptables.

5. Run Speed Test:

   • Initiate a speed test to measure download and upload speeds (Mbps).
   • Linux uses speedtest-cli; Windows uses WinArpSpoof.exe speedtest (windows upload speed test not implemented ).

6. Export Data:

   • Export the device list to table_data.xlsx for analysis.

Platform Implementations

Windows

• CLI Tool: WinArpSpoof.exe (GitHub).
• Key Operations:
  • Scanning: WinArpSpoof.exe scan to list devices (IP, MAC, hostname, vendor).
  • Blocking: WinArpSpoof.exe block <IP> with start for ARP spoofing.
  • Unblocking: WinArpSpoof.exe unblock <IP>.
  • Bandwidth: Uses wmic to query Win32_PerfFormattedData_Tcpip_NetworkInterface for BytesReceivedPersec and BytesSentPersec.
  • Speed Test: WinArpSpoof.exe speedtest for network performance (windows upload speed test not implemented ).
• Dependencies:
  • Winpcap for packet capture.
  • Admin privileges.
• Setup:
  • Place WinArpSpoof.exe in assets/.
  • Run with admin privileges:

    flutter run

• Notes:
  • The app automatically starts WinArpSpoof.exe on launch.
  • Cleanup ensures WinArpSpoof.exe stops on app exit.

Linux

• CLI Tools:

  • arp-scan: Network scanning.
  • arpspoof: ARP spoofing for blocking.
  • ebtables/iptables: MAC and IP-based firewall rules.
  • speedtest-cli: Speed testing.
  • dig: Hostname resolution.
  • arping: ARP table restoration.
  • ip: Interface and IP management.

• Key Operations:

  • Scanning: arp-scan --interface=<iface> --localnet to list devices.
  • Blocking: arpspoof -i <iface> -t <IP> <gateway> with ebtables and iptables to drop packets.
  • Unblocking: Stops arpspoof and removes ebtables/iptables rules, then uses arping to restore ARP tables.
  • Bandwidth: Reads /proc/net/dev for bytes received and sent, with a 1-second delta.
  • Speed Test: speedtest-cli --json for download/upload speeds in Mbps.

• Dependencies:

  • libpcap, arp-scan, dsniff, ebtables, iptables, dnsutils, speedtest-cli.
  • Root privileges.

• Setup:

  • Install dependencies:

    sudo apt update
    sudo apt install arp-scan dsniff ebtables iptables dnsutils python3-speedtest-cli libpcap-dev

  • Run with root privileges (the app is configured to ask for root privileges)

• Notes:

  • No asset files are needed; all tools are system-installed.
  • Cleanup stops arpspoof and unblocks all devices on app exit.

Project Structure

safwatx/
├── assets/
│   └── WinArpSpoof.exe          # Windows CLI tool
├── lib/
│   ├── models/
│   │   └── device_model.dart    # Device data model
│   ├── providers/
│   │   └── network_provider.dart # State management
│   ├── screens/
│   │   └── Dashboard/           # UI components
│   └── services/
│       ├── services.dart        # NetworkManager interface
│       ├── linux_network_manager.dart # Linux implementation
│       └── windows_network_manager.dart # Windows implementation
└── pubspec.yaml                 # Dependencies and assets

Troubleshooting

Windows

• WinArpSpoof.exe Fails to Start:
  • Verify it’s in assets/ and listed in pubspec.yaml.
  • Run with admin privileges.
  • Ensure winpcap is installed.
  • Test manually:

    WinArpSpoof.exe start

• Bandwidth Shows 0.0:
  • Generate network traffic (e.g., stream a video).
  • Check wmic output:

    wmic path Win32_PerfFormattedData_Tcpip_NetworkInterface get BytesReceivedPersec,BytesSentPersec

Linux

• Scanning Fails:
  • Ensure arp-scan is installed and accessible (sudo arp-scan --localnet).
  • Run with root privileges.
• Blocking Fails:
  • Verify arpspoof, ebtables, and iptables are installed.
  • Check for conflicting firewall rules:

    sudo iptables -L -v -n
    sudo ebtables -L

• Bandwidth Shows 0.0:
  • Confirm the correct interface (e.g., eth0):

    cat /proc/net/dev

  • Generate traffic (e.g., download a file).

⚠️ Ethical and Legal Reminder

ARP spoofing is a Man-in-the-Middle attack and is considered illegal or unauthorized on networks you don't own or manage. Always use this code only in educational labs or networks where you have explicit permission.

License

This project is licensed under the MIT License. See LICENSE for details.

Contact

• Maintainer: Ziad Safwat Elaraby (ziadsafwataraby@gmail.com)
• Repository: github.com/ZiadSafwat/SafwatX
• Windows CLI Tool: Website

---

Built with 💙 using Flutter and open-source tools.
