RISC-DCCCLXVII

A RISC-V-like CPU designed in SystemVerilog for a Hardware Infrastructure class.

Compiling and running

In the config folder there are three .do files that can be used to compile and run the project in any operating system:

• initsim.do will compile and run the simulation.
• compile.do will compile all files.
• waves.do will setup all the waves for the simulation.

Addidionaly, if you're in a Linux system, initsim.sh will set the correct PATH for your directory, setup and launch ModelSim with all the right configs.

There are two ways to use the included build scripts.

Using ModelSim

Open ModelSim. On the File menu, choose Change directory.
Open the root folder of the project. On the transcript window, type

do config/initsim.do

It should then compile and setup the simulation automatically.

Using VSCode on Linux

First, make sure ModelSim is in your PATH. Then, give all compile scripts executable permission:

sudo chmod +x config/*.do ; sudo chmod +x config/sh/initsim.sh

In VSCode, open the task menu with CTRL + ALT + B. Run Compile TOP first to compile all files, then run Run ModelSim to setup the simulation environment.

Folder structure

• bench: all testbench files
• config: scripts for running/compilation
• docs: diagrams and state machine visualizations
• hdl: all module files
  • hdl/memory: memory modules
  • hdl/packages: functions and constants
• libs: build folder
• mem: stores memory instructions for pre-load

Coding guidelines

• 4 space identation
• snake_case naming for all variables
• Don't specify in_ or out_ in signal names outside of module declarations.

« DON'T »             « DO »

wire i_signal;        module foo(
                        input wire i_signal
                      );

• Explicit . operator when using modules
• Clock is always clk, reset is always reset
• Always use enums instead of arbitrary binary values in state machines/selector pins

« DON'T »             « DO »

always_comb           enum {READ, WAIT} states;
  case (foo)          always_comb
    2'b00: ..           case (foo)
    2'b01: ..             READ: ..
    2'b11: ..             WAIT: ..

• Write the datatype for all variables. Only one declaration per line. Don't use implicit declaration.
