ilatex-editor

CKEditor 5 Equation editor by CDS for inline LaTeX formulas.

Part of Open CDS — open-source programs by Cipta Dua Saudara.

Features

• TypeScript CKEditor 5 plugin.
• Inline object widget: latexInline.
• Official package name: ilatex-editor.
• Creator: CDS / Cipta Dua Saudara.
• Program: Open CDS open-source programs.
• Repository: git@github.com:cds-id/ilatex.git.
• Plugin class: Equation.
• Toolbar/menu item: formula, labeled Formula.
• MS Word-like equation editor dialog using MathLive <math-field>.
• Visual equation editing, virtual keyboard support, symbol buttons, and raw LaTeX fallback textarea.
• Edit existing equation by selecting inline formula and clicking Formula.
• Double-click equation in editor to open edit dialog.
• MathLive virtual keyboard stays hidden by default.
• [% ... %] shortcode auto-parsing on load, paste, and typing.
• Standalone render utilities to display LaTeX outside the editor (React, SSR, plain DOM).
• Command: insertLatex.
• HTML data format:

<span class="latex-math" data-latex="E=mc^2">E=mc^2</span>

Install

npm install ilatex-editor

Peer runtime: ckeditor5 (for the editor plugin) and mathlive (rendering) ship as dependencies, so a plain install pulls everything. Works with any bundler that handles CSS imports (Vite, Webpack, Next.js, Rollup).

Package entry points:

Import	Use
ilatex-editor	CKEditor 5 Equation plugin + render utils
ilatex-editor/render	SSR-safe render utilities (no CKEditor, no CSS)
ilatex-editor/auto	Zero-config: renders the whole page on load
ilatex-editor/styles	MathLive static + font CSS (bundler only)

Usage in CKEditor 5

import 'ckeditor5/ckeditor5.css';
import 'mathlive/fonts.css';
import { ClassicEditor, Essentials, Paragraph } from 'ckeditor5';
import { MathfieldElement } from 'mathlive';
import { Equation } from 'ilatex-editor';

// Required: disable MathLive's runtime font probing. Bundlers serve the fonts
// via fonts.css @font-face; the runtime probe resolves to a wrong path and
// makes equations fall back to a system font.
MathfieldElement.fontsDirectory = null;

ClassicEditor.create( document.querySelector( '#editor' )!, {
	licenseKey: 'GPL',
	plugins: [ Essentials, Paragraph, Equation ],
	toolbar: [ 'formula' ]
} );

Programmatic insert:

editor.execute( 'insertLatex', { latex: 'E=mc^2' } );

Shortcode auto-parsing

The editor recognizes [% ... %] inline-math shortcodes on load, paste, and live typing — they convert to rendered formulas automatically:

[%x\lt2%]                  ->  x < 2
[%16\Large\frac{1}{3}%]     ->  16 ¹⁄₃

No configuration needed; type [%...%] anywhere in the editor.

About metadata:

Equation.about;
// { name: 'ilatex-editor', version: '0.1.0', creator: 'CDS' }

Rendering outside the editor

Render the same LaTeX (both [%...%] shortcodes and .latex-math[data-latex] spans produced by the editor) anywhere — no editor instance required.

Zero-config: render the whole page

import 'ilatex-editor/auto';

Importing this once renders all LaTeX in the document on DOMContentLoaded. It also pulls the required MathLive CSS + fonts. Re-render after dynamic DOM updates with the exported renderLatexInDocument().

Manual: render a subtree or a string

import 'ilatex-editor/styles';
import {
	renderLatexInElement,
	renderLatexInDocument,
	renderLatexToMarkup
} from 'ilatex-editor/render';

// Render every formula inside a container (idempotent, safe to re-run).
renderLatexInElement( '#article' );
renderLatexInElement( document.querySelector( '#article' )! );

// Render the whole page.
renderLatexInDocument();

// Render a single LaTeX string to static HTML markup (SSR-safe, no DOM).
const html = renderLatexToMarkup( 'x\\lt2' );

renderLatexInElement options:

renderLatexInElement( root, {
	shortcodes: true,      // convert [%...%] in text nodes (default true)
	mathSpans: true,       // render .latex-math[data-latex] spans (default true)
	renderedClass: 'latex-rendered' // marker class for idempotency
} );

Use in React

import { useEffect, useRef } from 'react';
import { renderLatexInElement } from 'ilatex-editor/render';
import 'ilatex-editor/styles';

export function Article( { html }: { html: string } ) {
	const ref = useRef<HTMLDivElement>( null );

	useEffect( () => {
		if ( ref.current ) {
			renderLatexInElement( ref.current );
		}
	}, [ html ] );

	return <div ref={ ref } dangerouslySetInnerHTML={ { __html: html } } />;
}

renderLatexToMarkup is SSR-safe (pure string, no CSS import), so you can also render on the server and ship static markup; load ilatex-editor/styles on the client for fonts.

Fonts

MathLive ships KaTeX woff2 fonts. In a bundler, import the CSS so @font-face URLs resolve correctly:

• Editor: import 'mathlive/fonts.css' + MathfieldElement.fontsDirectory = null.
• Render utils: import 'ilatex-editor/styles' (or ilatex-editor/auto, which imports it for you).

If you see OTS parsing error: invalid sfntVersion or equations in a fallback font, the runtime font probe is hitting a wrong path — apply the imports above.

Demo

npm run demo

• / — editor demo. Click Formula, use the MathLive field / symbol buttons / LaTeX textarea, or type a [%...%] shortcode. Double-click an equation to edit.
• /render-demo.html — standalone render (no editor) of shortcodes and .latex-math spans.

Tests

npm test -- --run
npm run typecheck
npm run build

Files

• src/equation.ts — master plugin and about metadata.
• src/latex.ts — compatibility export.
• src/latexediting.ts — schema, conversion, widget behavior, [%...%] post-fixer.
• src/latexui.ts — toolbar button.
• src/insertlatexcommand.ts — insert command.
• src/shortcode.ts — shared [%...%] pattern (editor + renderer).
• src/render.ts — standalone render utilities (no editor).
• src/auto.ts — zero-config auto-render entry point.
• src/styles.ts — MathLive CSS + fonts side-effect import.
• tests/latex-plugin.test.ts — CKEditor integration tests.
• tests/render.test.ts — render utility tests.
• sample/ — demo app (/ editor, /render-demo.html standalone render).
