SubCortexMesh

Surface-based postprocessing of segmented subcortices in Python

This toolbox provides commands for surface based measures of subcortical segmentations from FreeSurfer and FSL FIRST, including thickness, surface area and curvature. Depending on the segmentation algorithm, compatible subcortices are: the Thalamus, Caudate, Putamen, Pallidum, Hippocampus, Amygdala, Accumbens-area, Ventral diencephalon, Cerebellum-Cortex, and the Brain-Stem.

Workflow

The toolbox automatically converts a subjects directory's subcortical segmentation volumes to 3D surface meshes. SubCortexMesh:

• Rigidly coregisters subject-space volumes to a template space (MNI). It solely does rotation and no interpolation to preserve subject-space dimensions.

• Extracts individual regions-of-interest (ROIs) as separate volumes

• Converts each volume to surface meshes using VTK's Discrete Marching Cube protocol, with additional dilating+eroding and smoothing to minimise artefacts (can be disabled or lowered)

• Measures vertex-wise thickness (radial distance from a generated medial curve), surface area (1/3 of the area of the triangles a vertex is part of) and curvature (mean curvature).

• Saves descriptive statistics for each ROI in a table for each subject and metric.

• Aligns subject meshes and projects their vertex-wise values to a standard template-based surface, based on fsaverage/MNI305 for FreeSurfer outputs,¹ and MNI152 for FSL FIRST outputs². The native space meshes, with their associated scalar metrics, can also be saved.

Installation

SubCortexMesh can be installed via pip from the GitHub directory:

pip install git+https://github.com/chabld/SubCortexMesh.git

All SubCortexMesh computations are fully executed in Python, most functions mainly relying on the VTK v9.5.2 module. Once imported in python, the toolbox requires base template data to be downloaded. The command below is triggered by every function that needs the data. It checks for its existence and if it is not found, it will assist users so they can download it in a default or custom path:

from subcortexmesh import template_data_fetch
toolboxdata=template_data_fetch(template='fsaverage') #or 'fslfirst'

Getting started

Extracting and coregistering subcortical volumes

The extraction of segmentation volumes is done on preprocessing subjects directories, where subcortical segmentations are available. Typically, a subject directory is the output $SUBJECTS_DIR for FreeSurfer's recon-all pipeline, and a directory where run_first_all has sent its output in FSL. SubCortexMesh finds all subjects inside the directory and extracts their subcortical segmentation volumes ("aseg.mgz" in FreeSurfer,"*all_fast_firstseg.nii.gz" in FSL). To facilitate later standardisation, those volumes are coregistered to their respective templates (fsaverage/MNI305 for FreeSurfer, MNI152 for FSL).

Below is the command that automatically extracts and coregisters all subcortical volumes of a subjects directory:

from subcortexmesh import subseg_getvol
subseg_getvol(
  inputdir="FreeSurfer_sub_directory/",
  outputdir="/my_outputdir/",
  #toolboxdata="/user_path/subcortexmesh_data",
  overwrite=False,
  silent=False)

Notes:

• The path to the toolboxdata argument only needs to be specified if it was not downloaded to the default path, i.e. the user's home directory

• SubCortexMesh follows the sub-*** convention for participant IDs and will only account for folders with names that contain such IDs.

• In FSL FIRST, optional cerebellar surfaces also need to be named *L-Cereb_first.nii.gz and *R-Cereb_first.nii.gz.³

• The coregistration requires T1 volumes to be present for each subject: it should be stored as [sub-ID]/mri/T1.mgz for FreeSurfer and stored in the same "inputdir" path for FSL FIRST (the function will search for files containing the sub-ID and "T1w.nii" for each subject).

Converting volumes to surfaces

subseg_getvol() will create a directory called "sub_volumes" inside the path given (outputdir). The path to sub_volumes can then be given to the following command in order to convert the volumes into surfaces:

from subcortexmesh import vol2surf
vol2surf(
    inputdir="/my_outputdir/sub_volumes",
    outputdir="/my_outputdir/",
    #dilate_erode=True,
    #smoothing=15,
    plot_volnext2surf=True,
    overwrite=False,
    silent=False
    )

The plot_volnext2surf() argument is False by default, but allows users to check if they are satisfied with the resulting mesh. Below is an example with a left thalamus: A) shows the volume and the surface created from the former superimposed, B) the voxel-based volume, C) the vertex-wise surface (with VTK' discrete marching cubes method, no smoothing), D) the surface after dilation+erosion and smoothing.

Similarly, vol2surf() will create a directory called "sub_surfaces" inside the given outputdir.

Visualising converted surfaces meshes

The surfaces stored in "sub_surfaces" can also be plotted together on top of a subject's corresponding volume with the surf_qcplot() function. Because the surfaces are based on a volume rigidly coregistered to fsaverage, the surfaces will match a volume generated with subseg_getvol(), i.e. "sub_volumes/sub-[id]/ants_coreg/T1_[template]_rigid_coreg.nii.gz" (or any volume likewise coregistered):

from subcortexmesh import surf_qcplot
surf_qcplot(
    volpath="/my_outputdir/sub_volumes/sub-[id]/ants_coreg/T1_fsaverage_rigid_coreg.nii.gz",
    surfdir="/my_outputdir/sub_surfaces/sub-[id]",
    vol_color_map= "gray",
    outline_color_map = "tab20"
    )

Since regions will have been inflated and smoothed by default to minimise graphical artefacts (e.g. hanging sparse voxels, sharp mesh spikes), the boundaries naturally appear slightly wider than their original anatomy and overlapping. Note that because the surfaces are processed by SubCortexMesh entirely separately, the visual overlap has no effect on later metrics values. In any event, this can be run on surfaces produced with dilate_erode=False.

Computing surface-based metrics

The path to sub_surfaces/ can then be given to the following command in order to compute mesh-wise metrics:

from subcortexmesh import mesh_metrics
mesh_metrics(
  inputdir="/my_outputdir/sub_surfaces",
  outputdir="/my_outputdir/",
  #toolboxdata="/user_path/subcortexmesh_data",
  template='fsaverage',
  metric=['thickness','surfarea','curvature'], #default, can also be one string
  #roilabel=['left-thalamus','right-thalamus'], #if one wants to only compute specific ROIs
  smooth=[0,5,5], #FMHW smoothing for: thickness, surface area, curvature
  plot_medial_curve=True,
  plot_projection=True,
  native_meshes=True,
  overwrite=True,
  silent=False)

The measure will create a "surface_metrics/" directory in the outputdir. The native_meshes argument gives the option to also save .vtk surface meshes in native space, containing the scalars for each metric.

mesh_metrics() also saves native summary statistics tables in each subject directory. E.g., surface_metrics/sub-xxx/surfarea_stats.txt:

label	mean	sd	min	max	range	n_vert
left-accumbens-area	0.683	0.205	0.158	1.242	1.084	806
right-accumbens-area	0.677	0.205	0.184	1.146	0.962	886
left-amygdala	0.685	0.199	0.159	1.254	1.095	1288
...

The plotting arguments are also False by default and allow users to check the computation process. The medial curve, the line crossing through the centre of the mesh (A) is fundamental to the thickness measure, as it is a measure of radial distance between the medial curve and the outer surface. It is also used to align the subject-space and template-space mesh further. Likewise, plotting the subject surface (B) and its template equivalent (C) shows how accurate the standardisation was.

Merging all surfaces

It is possible to treat all ROIs as one and merge their vertex-wise surface metrics into one big mesh. This is what the following command accomplishes, subject-per-subject (provided all subcortical meshes have been created, including the cerebella for FSL FIRST, cf. footnote 3):

from subcortexmesh import merge_all
merge_all(
  inputdir="/my_outputdir/surface_metrics/,
  #toolboxdata="/user_path/subcortexmesh_data",
  template='fsaverage',
  plot_merged=True,
  overwrite=False,
  silent=False)

The mesh is saved in the sub_surfaces/ subject directories, e.g. allaseg_thickness.vtk for fsaverage based surfaces. The plotter lets you visualise the outcome of the merging:

Statistical analyses

Users can run statistical analyses on the surface-based metrics with any potential software that can work with .vtk meshes and read their metrics scalars. SubCortexMesh provides a small wrapper for BrainStat's SLM analysis tools, which fit linear or linear mixed models with surface-based values.

The slm_analysis() function facilitates the process of collating surface data by reading scalars from every surface available with a selected region and metric, and appending them into a single numpy array (N subjects x V vertices). The collated meshes are ordered alphanumerically according to the subject IDs of the surface_metrics/ subfolders, so users need to make sure their model/contrast variables match that order too.

The other arguments are that of the SLM function. Here is an example:

import pandas as pd
from brainstat.stats.terms import FixedEffect
from subcortexmesh import slm_model, slm_plot
#hypothetical behavioural data
beh_data = pd.read_csv("participants.tsv", sep="\t")
beh_data = beh_data.dropna(subset=['age'])
#prepare model as per BrainStat's terms system
model = FixedEffect(beh_data['age'])
contrast = beh_data['age']
#Testing the effect of age on left-thalamus thickness
slm_model = slm_analysis(
    inputdir="surface_metrics/",
    template='fsaverage',
    metric='thickness',
    roilabel='left-thalamus',
    model=model,
    contrast=contrast,
    correction=["fdr", "rft"],
    cluster_threshold=0.05,
    smooth=5, #optional FMHW smoothing of the metric values
    sub_list=beh_data['participant_id'] #optional inclusion list to avoid mismatching model and surface data
)

Once the analysis is complete, the outputted maps in the SLM object (here slm_model) can be visualised as follows:

slm_plot(
  slm=slm_model,
  stat='clusters',
  cmap='RdBu_r',
  #threshold= .05,
  #smooth_mesh=0 #cosmetic mesh smoothing
  )

Other options for the "stat" argument include 't' for the t-statistics map, 'p_fdr' for the false discovery rate-corrected p-value map, 'p_rft' for the random field theory cluster corrected p-values.

More advanced sets of analysis and plotting tools, including BrainStat's SLM as well as threshold-free cluster enhancement cluster analyses, are available in the R package VertexWiseR, which is able to extract and analyse outputs from SubCortexMesh.

Footnotes

1. The fsaverage/MNI305 surface-based templates for each ROI have been produced by using SubCortexMesh's own functions (subseg_getvol(), vol2surf()) with default parameters, on the fsaverage template's own aseg.mgz in FreeSurfer 7.4.1 ($FREESURFER_HOME/subjects/fsaverage/mri/aseg.mgz). ↩

2. The fslfirst/MNI152 surface-based templates for each ROI have also been produced by using SubCortexMesh's own functions (subseg_getvol(), vol2surf()) with the same parameters (except smoothing=20). The segmentations volumes were obtained using FSL v.6.0.6's own probabilistic models (.bmv files in $FSLDIR/data/first/models_336_bin/) on the standard MNI 152 1mm T1w volume ($FSLDIR/data/standard/MNI152_T1_1mm_brain.nii.gz). Cerebellar meshes were produced using run_first, with "-n 40" modes, using the putamen intensities to normalise its intensity sample as recommended by the latter's documentation. ↩

3. Cerebellar segmentations can be done in FSL with the following commands (do the same for L_Cereb):
   first_flirt [subject's T1file] "[subject's subdirectory]/[sub-id]" -cort
run_first -i [subject's T1file]
-t "[subject's subdirectory]/[sub-id_cort.mat]"
-n 40
-o "[subject's subdirectory]/[sub-id]-R_Cereb_first"
-m "${FSLDIR}/data/first/models_336_bin/intref_puta/R_Cereb.bmv"
-intref "${FSLDIR}/data/first/models_336_bin/05mm/R_Puta_05mm.bmv"

   The putamen used as the intensity reference is what is indicated by FSL FIRST's documentation and 40 is just the number of modes used for most ROIs. ↩
