S-UI-X Extended

English | Русский

Support S-UI-X Extended

S-UI-X Extended is an open-source project. Donations help pay for development, security work, testing, and release preparation.

• WEB: https://web.tribute.tg/d/LRJ
• Telegram: https://t.me/tribute/app?startapp=dLRJ

Network	Address
TON	UQB5-DZ3q5vjXGf3_tVUeOHPNuXMLh8lfY0MPW3uGzjdOzke
ETH	0x0e67e1b4363a163c36943Ef4F9227c3126bB952B
SOL	BtFm5E1BrUjpoaDNwv3emc2qbyvqkn6ECnDzwhgRn7Df
TRX	TFqEbp1Z82ZQebzDdsW1MbytMvVsHJGpPd
BTC	bc1qn86mfmsnackfwvjd4czjaalv75sh830fws7xc9

S-UI-X Extended is a web panel built on sing-box-extended, the shtorm-7 fork of SagerNet/sing-box.

This repository is based on alireza0/s-ui from v1.4.1. It keeps parity with upstream s-ui-x v1.5.10-beta7 and runs on the sing-box-extended core.

You can use the published install scripts, or fork the repository and build it yourself.

Disclaimer: this project is intended only for personal learning and knowledge sharing. Do not use it for illegal purposes.

Releases

Configuration and usage guides:

• English guide: docs/INSTRUCTIONS-EN.md
• Russian guide: docs/INSTRUCTIONS-RU.md

Release history and upgrade notes:

• English changelog: CHANGELOG-EN.md
• Russian changelog: CHANGELOG-RU.md
• Simplified Chinese changelog: CHANGELOG-ZH.md
• Latest stable notes: docs/releases/v1.0.7.md
• Upstream parity reference: docs/releases/v1.5.10-beta7.md

How this differs from alireza0/s-ui

Show details

This fork is built to stay compatible with existing 1.x installs. You can replace the binary on an existing server, and the panel runs database migrations on first start. Protocol behavior stays close to upstream; most changes are in security, operations, observability, release handling, and the admin UI.

• Fresh installs create a random first admin password. Passwords use bcrypt, browser sessions use hardened cookies, mutating browser API calls require CSRF protection, and API tokens are hashed with admin, read, write, or observability scopes.
• Telegram credentials, proxy credentials, install salt, and other sensitive settings are encrypted at rest with secretbox. Telegram messages, audit details, backup captions, and change history are redacted before they leave the panel.
• Network-facing inputs have stricter checks. X-Forwarded-For is ignored unless trusted proxies are configured. External subscription fetches validate URLs and resolved IPs, block private and loopback targets by default, cap responses at 4 MiB, and re-check IPs at dial time.
• Subscriptions support per-client secrets for link, JSON, and Clash formats. Legacy name-based subscription URLs still work while subSecretRequired=false. Subscription responses sanitize headers, apply per-IP rate limits, support gzip, and cache successful output briefly.
• sing-box runs as an embedded Go library rather than a subprocess. Saves for clients, TLS, inbounds, outbounds, endpoints, and services hot-apply the affected object where possible. A full restart is used only when a change requires it or hot apply cannot keep the running config safe.
• Routing includes panel-managed outbound groups and provider-backed membership. Selector, URLTest, fallback, and failover groups include tag validation, previews, and capability metadata. The panel-managed failover type checks members over HTTPS, moves new connections away from a failed active member, and supports explicit all-down policies.
• The panel can update itself from Settings. Admins can check stable or beta releases, verify the downloaded binary against the release SHA-256, apply the update, and roll back automatically if the new binary repeatedly fails to start. The action is audited and requires password re-entry.
• Backup and import flows are more defensive. Imports enforce a 64 MiB cap, SQLite magic checks, staging, read-only integrity checks, schema migrations, and rollback to the previous database on failure. Local unencrypted database export streams the prepared SQLite file instead of buffering the whole backup in memory.
• Audit and observability are built in. The panel stores audit events with retention cleanup, exposes a scoped and paginated audit API, keeps bounded logs, samples bounded observability buckets, and publishes realtime events through a hardened WebSocket path with single-use tokens and Origin checks.
• Client IP history uses salted hashes by default. Raw IP display is opt-in, retention is configurable, and enforce mode rejects only new over-limit connections instead of closing active ones.
• Panel and subscription HTTP servers use read, write, header, and idle timeouts. TLS uses MinVersion = 1.2. Security headers are enabled, and subscription responses are marked no-store. If a saved listen IP no longer exists on the host, fallback stays restricted instead of silently widening exposure.
• Nexus is the main panel interface. Shared pages still reuse existing components where practical, settings show defaults and help text, update release notes render as safe Markdown, and route-based code splitting keeps heavy views out of the initial page load.
• Performance work covers daily operations: optimized stats queries and chart downsampling, batched stats writes, less duplicated settings reads in /api/load, parallel reads for independent load data, one marshal per WebSocket broadcast, and split frontend vendor chunks for browser caching.
• The panel, install script, and terminal menu include English, Russian, and Chinese localization.

Supported Protocols

Show supported protocols

This list follows the repository capability matrix. Some protocols, endpoints, and services require builds with the matching core tags.

Inbound protocols

Protocol	Notes
Socks
HTTP
Mixed	Socks + HTTP on one port
Shadowsocks	AEAD ciphers, 2022 methods
VMess	UUID auth, xudp/gRPC/WS
VLESS	Reality / TLS transport
Trojan	HTTPS camouflage, fallback
Naive	Chromium network stack
Hysteria	QUIC transport
Hysteria2	QUIC transport
TUIC	QUIC transport
AnyTLS
ShadowTLS	Detour to hidden protocol
Mieru	Stealth protocol
Sudoku	HTTP mask obfuscation; automatic per-client split-key delivery
TrustTunnel	QUIC tunnel
SSH	SSH server emulation
MTProxy	Telegram proxy, FakeTLS, delivered as tg://proxy
Direct	Port forward / relay
Tun	Virtual network interface
Redirect	Linux redirect transparent proxy
TProxy	Linux transparent proxy
Bond	Native core aggregate inbound
Core failover	Native core failover inbound

Outbound protocols

Protocol	Notes
Direct	Raw traffic, no proxy
Block	Silently drop traffic
Socks
HTTP
Shadowsocks
VMess
VLESS
Trojan
Naive
Tor	SOCKS5 to Tor daemon
SSH
ShadowTLS
AnyTLS
Mieru
TrustTunnel
Sudoku
MASQUE
OpenVPN
Hysteria
Hysteria2
TUIC
Core failover	Native core dial-time failover

Outbound groups

Type	Managed by	Notes
Selector	Core	Manual switch, operator picks member
URLTest	Core	Auto-select lowest-latency member
Fallback	Core	Connect-time failover
Failover	Panel	Periodic health checks and all-down policies; affects new connections

Providers

Type	Notes
Inline	Hand-written members in panel
Local	Local file provider
Remote	Remote subscription provider

Endpoints

Type	Notes
WireGuard	Requires WireGuard-enabled core build
Tailscale	Requires Tailscale-enabled core build
VPN	WARP/VPN client and server endpoint

Core services

Service	Notes
resolved	DNS resolver service
ssm-api	SSM API service
derp	DERP service
ccm	Requires CCM-enabled core build
ocm	Requires OCM-enabled core build
oom-killer	Requires oom-killer-enabled core build
profiler	Development profiling service

Supported Platforms

Platform	Architecture	Status
Linux	amd64, arm64, armv7, armv6, armv5, 386, s390x	Supported
Windows	amd64, 386, arm64	Supported
macOS	amd64, arm64	Experimental support

Default Installation Information

• Panel port: 2095
• Panel path: /app/
• Subscription port: 2096
• Subscription path: /sub/
• Subscription per-IP rate-limit changes (subRateLimitPerIP) take effect within 1 minute after saving.
• Username: admin
• Password for a fresh install: a random 24-character string is generated on first start and written to the application log. Look for created initial admin user. username=admin password=... in journalctl -u s-ui on Linux or in the panel log on first run. Change it from the panel after you sign in.

Install or upgrade

Use the stable build for normal installations. Use beta releases only if you want to test changes before they become stable.

Channel	Version	Notes
Stable	v1.0.7	Recommended for production. Keeps the management menu available while the service is starting, improves Sudoku key controls, and makes the domain-reset action stop using panel and subscription certificates. Release notes: docs/releases/v1.0.7.md.

Linux/macOS, stable

bash <(curl -Ls https://raw.githubusercontent.com/deposist/s-ui-x-extended/v1.0.7/install.sh)

The command above installs the latest stable release. Pass a version tag explicitly if you need a specific beta or older build.

Local clone

git clone --branch v1.0.2 --depth 1 https://github.com/deposist/s-ui-x-extended.git
cd s-ui-x-extended
sudo bash install.sh v1.0.2

Windows

• Stable: download v1.0.2 from its release page, extract the ZIP, and run install-windows.bat as Administrator.

Existing installations keep their settings, users, inbounds, outbounds, clients, TLS, services, and tokens. Database migrations run automatically on first start. Upgrade and rollback notes are in the changelog files: EN, RU, 中文.

Manual Installation

Show manual installation steps

Linux/macOS

1. Download the latest S-UI-X Extended version for your system and architecture from GitHub: https://github.com/deposist/s-ui-x-extended/releases/latest
2. Optional: download the latest s-ui.sh: https://raw.githubusercontent.com/deposist/s-ui-x-extended/v1.0.2/s-ui.sh
3. Optional: copy s-ui.sh to /usr/bin/ and run chmod +x /usr/bin/s-ui.
4. Extract the S-UI-X Extended tar.gz archive to your chosen directory and enter the extracted folder.
5. Copy the *.service files to /etc/systemd/system/, then run systemctl daemon-reload.
6. Run systemctl enable s-ui --now to enable autostart and start the s-ui service used by S-UI-X Extended.
7. Run systemctl enable sing-box --now to start the sing-box service.

Windows

1. Download the latest Windows version from GitHub: https://github.com/deposist/s-ui-x-extended/releases/latest
2. Download the appropriate Windows package, for example s-ui-windows-amd64.zip.
3. Extract the ZIP file to your chosen directory.
4. Run install-windows.bat as Administrator.
5. Follow the installation wizard.
6. Open the panel: http://localhost:2095/app

Uninstall S-UI-X Extended

sudo -i

systemctl disable s-ui  --now

rm -f /etc/systemd/system/sing-box.service
systemctl daemon-reload

rm -fr /usr/local/s-ui
rm /usr/bin/s-ui

Docker Installation

Show details

Usage

Step 1: install Docker

curl -fsSL https://get.docker.com | sh

Step 2: install S-UI-X Extended

Docker Compose option:

services:
  s-ui:
    image: ghcr.io/deposist/s-ui-x-extended
    container_name: s-ui-x-extended
    hostname: "s-ui-x-extended"
    network_mode: host
    volumes:
      - "./db:/app/db"
      - "./cert:/app/cert"
    tty: true
    restart: unless-stopped
    entrypoint: "./entrypoint.sh"

docker compose up -d

Direct Docker run:

mkdir s-ui-x-extended && cd s-ui-x-extended

docker run -itd \
    --network host \
    -v $PWD/db/:/app/db/ \
    -v $PWD/cert/:/root/cert/ \
    --name s-ui-x-extended \
    --restart=unless-stopped \
    ghcr.io/deposist/s-ui-x-extended

Build the image yourself:

git clone https://github.com/deposist/s-ui-x-extended
docker build -t s-ui-x-extended .

Manual Run for Development and Contributions

Show details

Build and Run the Full Project

./runSUI.sh

Clone the Repository

git clone https://github.com/deposist/s-ui-x-extended

Frontend

The frontend code is in the frontend directory.

Backend

Build the frontend at least once before building the backend.

Build the backend:

rm -fr web/html/*
cp -R frontend/dist/ web/html/
go build -o sui main.go

Run the backend from the repository root:

./sui

Languages

• English
• Persian
• Vietnamese
• Simplified Chinese
• Traditional Chinese
• Russian

Environment Variables

Show details

Usage

Variable	Type	Default
SUI_LOG_LEVEL	"debug" | "info" | "warn" | "error"	"info"
SUI_DEBUG	boolean	false
SUI_BIN_FOLDER	string	"bin"
SUI_DB_FOLDER	string	"db"
SINGBOX_API	string	-
SUI_TRUSTED_PROXIES	comma-separated CIDRs or IPs	none, XFF ignored
SUI_ALLOW_PRIVATE_SUB_URLS	boolean	false
SUI_SECRETBOX_KEY	string	none, falls back to settings.secret

For systemd installs run by install.sh, S-UI-X Extended generates a stable SUI_SECRETBOX_KEY once in /etc/s-ui/secretbox.env, shows the generated value once, and loads the file through a systemd drop-in. Keep that file private and preserve the same key across updates and restores.

SSL Certificates

Show details

Certbot

snap install core; snap refresh core
snap install --classic certbot
ln -s /snap/bin/certbot /usr/bin/certbot

certbot certonly --standalone --register-unsafely-without-email --non-interactive --agree-tos -d <your domain>

Credits

• Original panel project: alireza0/s-ui
• Extended core: shtorm-7/sing-box-extended
