🐾 Fitty — AI Cat Health Tracker

#hackthekitty 2026 | 😼 World Cat Domination Day

Fitty estimates your cat's Body Condition Score (BCS) from two photos using AI vision, with optional voice note context. Features an always-on Vet AI chat for follow-up questions about your cat's health. Built as a Universal App (iOS, Android, Web) with durable AI execution powered by Temporal.io.

🔗 Live Demo: fitty-demo.vercel.app

---

🚀 Quick Start (Judges)

Visit the live demo and tap "Continue as Guest (Judges)" — no setup required. The app provides a full simulated experience with pre-seeded data.

🤖 Judge AI Assistant

A floating AI chatbot is available on every page of the web app. Ask it anything about our architecture, features, or stack — it responds instantly via GPT-4o-mini with full project context.

🎤 Pitch Presentation

Navigate to /presentation to view the interactive, in-app pitch presentation detailing the problem, solution, and architecture.

🎬 Video Demo

---

✨ Key Features

• AI Body Condition Scoring — Two-photo analysis (top + side view) using Claude 5.
• Voice Note Context — Audio observations auto-transcribed by OpenAI Whisper.
• Durable AI Execution — Temporal.io guarantees workflow completion with automatic retries.
• Contextual AI Chat — Follow-up Q&A about specific health reports.
• Interactive Trend Tracking — BCS history chart showing health progression over time.
• Multi-cat Support — Manage multiple cat profiles effortlessly.

---

📋 Prerequisites

• Node.js ≥ 18
• Yarn (package manager)
• Expo CLI (npx expo)

External Services (required for full functionality)

Service	Purpose	Free Tier
Supabase	Auth, Database, Storage, Realtime	✅
Temporal Cloud	Durable AI workflow execution	✅ Dev
Anthropic	Claude Sonnet 5 (vision + reasoning)	Pay-as-you-go
OpenAI	Whisper (audio transcription)	Pay-as-you-go

---

🛠️ Local Setup

1. Clone & Install

git clone https://github.com/gonzagramaglia/fitty.git
cd fitty
yarn install

2. Environment Variables

Create a .env file in the project root:

# Supabase (Frontend)
EXPO_PUBLIC_SUPABASE_URL=https://your-project.supabase.co
EXPO_PUBLIC_SUPABASE_ANON_KEY=your-anon-key

# Backend API URL (Render or localhost)
EXPO_PUBLIC_CHAT_API_URL=http://localhost:3001/api/chat

For the backend worker, create a separate .env or set these in your environment:

# Supabase (Backend — service role)
SUPABASE_URL=https://your-project.supabase.co
SUPABASE_SERVICE_ROLE_KEY=your-service-role-key

# AI APIs
ANTHROPIC_API_KEY=sk-ant-...
OPENAI_API_KEY=sk-...

# Temporal Cloud
TEMPORAL_ADDRESS=your-ns.xxxxx.tmprl.cloud:7233
TEMPORAL_NAMESPACE=your-ns
TEMPORAL_TLS_CERT=<certificate content>
TEMPORAL_TLS_KEY=<key content>

3. Run the Frontend

npx expo start

Open in browser at http://localhost:8081 (Web) or scan the QR code for mobile.

4. Run the Backend Worker

npx tsx temporal/worker.ts

This starts both the Express API server (chat + analyze endpoints) and the Temporal worker.

---

🏗️ Project Structure

fitty/
├── app/                  # Expo Router pages (tabs, auth, camera, presentation)
│   └── api/             # Expo API routes (chat endpoint for Judge AI)
├── components/           # Reusable UI components
│   ├── ui/              # General UI (BCSGauge, ChatModal, etc.)
│   ├── camera/          # Camera-specific (SilhouetteOverlay, ProcessingScreen)
│   ├── JudgeChat.tsx    # Floating AI chatbot for hackathon judges
│   └── GitHubLink.tsx   # GitHub link component
├── hooks/               # Custom React hooks (useHistory, useHealthCheck, etc.)
├── lib/                 # Shared utilities (supabase, types, validators)
├── temporal/            # Temporal workflows, activities, Express server
├── context/             # Project documentation (architecture, build plan, etc.)
├── docs/                # Testing report, project report
├── journal/             # Video script, design prompts
├── __tests__/           # Unit tests (Jest)
└── assets/              # Images, fonts

---

🧪 Running Tests

yarn test

Result: 54/54 tests passing ✅

See docs/testing.md for the full manual test matrix.

---

📖 Documentation

Document	Description
docs/project-report.md	Full hackathon project report
docs/testing.md	Automated + manual test documentation
docs/aikido/	Aikido AI Security scan report screenshots
context/architecture.md	Technical architecture & data flows
context/build-plan.md	Phase-by-phase build plan
context/progress-tracker.md	Task completion tracker
context/ui-tokens.md	Design system tokens (colors, typography)
context/ui-rules.md	UI component rules & patterns
context/ui-registry.md	Component registry (all built components)
context/code-standards.md	Engineering conventions & rules

---

🔒 Security

• Aikido Security — AI Code Audit completed with findings resolved. See full scan report →
• Row Level Security (RLS) — All Supabase tables enforce user-scoped access
• Service Role Isolation — Backend uses service key, frontend uses anon key only
• Rate Limiting — All API endpoints limited to 3–5 req/min per IP
• Input Validation — 500-char message limit, form field filtering, max lengths enforced
• Error Sanitization — Internal errors never exposed to clients (generic 500 responses)
• Auth Guards — Every API endpoint validates JWT before processing
• Prompt Injection Defense — User-supplied text sanitized and isolated in delimited data blocks
• Ownership Verification — Temporal worker validates record ownership before every write (defense-in-depth)
• Guest Quota Enforcement — Server-side per-anonymous-user limit prevents AI resource exhaustion
• No exposed secrets — All API keys server-side only, never prefixed with EXPO_PUBLIC_
• HTTPS only — All external links use noopener,noreferrer

📊 Aikido Scan Report

---

🏆 Hackathon Sponsors

Sponsor	Integration
Temporal.io	Core of our architecture — durable AI workflow orchestration with automatic retries, real-time step updates visible to the user, and graceful failure handling. The "Still Processing" screen and retry-on-failure both showcase Temporal's durable execution guarantees.
Aikido Security	AI Code Audit identified 5 threat scenarios + dependency CVEs. All findings resolved via code hardening (prompt injection defense, ownership verification, guest quotas) and dependency patching. Scan report included in docs/aikido/.
Kiro	Primary development environment for the final 4 tasks (UX polish, refactoring, E2E verification, documentation). Steering files in .kiro/ provided persistent project context across sessions.

---

🛠️ Other Key Tools

• Supabase — Managed PostgreSQL, Auth, Storage, and Realtime subscriptions.
• CodeRabbit — Automated AI code review on every Pull Request to maintain high code quality.
• Vercel & Render — Frontend static export hosting (Vercel) and backend Express/Temporal worker hosting (Render).

---

😼 Theme: World Cat Domination Day

Fitty directly drives positive impact for cats by:

• Preventing pet obesity — the #1 preventable health issue affecting 60%+ of domestic cats
• Democratizing veterinary assessments — BCS scoring was previously only available during vet visits
• Reducing stress — no more wrestling cats onto scales or anxious vet trips for routine weight checks
• Enabling early detection — trend tracking catches weight changes before they become health problems

The theme isn't surface-level — it's the core purpose of the entire application.

---

📄 License

MIT
