vault-mcp

A containerized Model Context Protocol (MCP) server for interacting with HashiCorp Vault. This server provides MCP tools for reading, writing, listing, and deleting secrets in Vault.

Features

• vault_read: Read secrets from Vault at a specified path
• vault_write: Write secrets to Vault at a specified path
• vault_list: List secrets at a specified path in Vault
• vault_delete: Delete secrets from Vault at a specified path

Prerequisites

• Docker and Docker Compose
• Docker Desktop 4.42.0+ with MCP Toolkit enabled (for Docker Desktop integration)
• HashiCorp Vault instance (can use the included dev server)
• Vault token for authentication

Quick Start

Option 1: Docker Desktop MCP Toolkit (Recommended)

Run the setup script to install and configure the server:

Windows (PowerShell):

.\setup.ps1

macOS/Linux (Bash):

./setup.sh

What the setup script does:

• Builds the Docker image if needed
• Starts Vault dev server
• Creates the MCP catalog in Docker Desktop
• Adds and enables the vault-mcp server

Configuration used:

• Catalog file: configs/vault-catalog.yaml
• Vault address: http://host.docker.internal:8200
• Vault token: myroot (dev mode)

After running the setup script, restart Docker Desktop to see the server in the "My Servers" section.

See docs/INSTALL_DOCKER_DESKTOP.md for detailed installation instructions.

Option 2: Docker Compose

Start both Vault and the MCP server:

# Build and start services
docker-compose up -d

# Check logs
docker-compose logs -f vault-mcp

This will start:

• A Vault dev server at http://localhost:8200 with root token myroot
• The vault-mcp server connected to the Vault instance

MCP Client Setup

Cursor IDE

Step 1: Copy the configuration

Copy configs/mcp_config.json to your Cursor MCP configuration file:

Windows:

# Create directory if it doesn't exist
New-Item -ItemType Directory -Force -Path "$env:USERPROFILE\.cursor"

# Copy the config file
Copy-Item -Path "configs\mcp_config.json" -Destination "$env:USERPROFILE\.cursor\mcp.json"

macOS/Linux:

# Create directory if it doesn't exist
mkdir -p ~/.cursor

# Copy the config file
cp configs/mcp_config.json ~/.cursor/mcp.json

Step 2: Update the configuration (if needed)

Edit ~/.cursor/mcp.json (or %USERPROFILE%\.cursor\mcp.json on Windows) and update:

• VAULT_ADDR: Your Vault server address
• VAULT_TOKEN: Your Vault token
• Image name: Use vault-mcp-vault-mcp:latest if built locally

Step 3: Restart Cursor

Completely quit and restart Cursor for the changes to take effect.

Step 4: Test

In Cursor, try asking:

Use vault_read to read the secret at path secret/data/test

See docs/TEST_CURSOR_MCP.md for more testing instructions.

Claude Desktop

Copy the configuration from configs/mcp_config.json to your Claude Desktop configuration:

Windows:

# Location: %APPDATA%\Claude\claude_desktop_config.json
Copy-Item -Path "configs\mcp_config.json" -Destination "$env:APPDATA\Claude\claude_desktop_config.json"

macOS:

# Location: ~/Library/Application Support/Claude/claude_desktop_config.json
cp configs/mcp_config.json ~/Library/Application\ Support/Claude/claude_desktop_config.json

Linux:

# Location: ~/.config/claude-desktop/claude_desktop_config.json
cp configs/mcp_config.json ~/.config/claude-desktop/claude_desktop_config.json

Then restart Claude Desktop.

Building the Docker Image

Using Pre-built Images from GitHub Container Registry

Pre-built container images are automatically published to GitHub Container Registry:

# Pull the latest image
docker pull ghcr.io/kelleyblackmore/vault-mcp:latest

# Pull a specific version
docker pull ghcr.io/kelleyblackmore/vault-mcp:v1.0.0

The images are automatically built for multiple platforms:

• linux/amd64 (x86_64)
• linux/arm64 (ARM64/aarch64)

Building Locally

docker-compose build vault-mcp
# Or
docker build -t vault-mcp-vault-mcp:latest .

Running the Container

With Docker Run

docker run -it --rm \
  -e VAULT_ADDR=http://host.docker.internal:8200 \
  -e VAULT_TOKEN=myroot \
  vault-mcp-vault-mcp:latest

With Docker Compose

Edit the docker-compose.yml file to configure your Vault connection:

environment:
  VAULT_ADDR: http://vault:8200
  VAULT_TOKEN: your-token

Then run:

docker-compose up vault-mcp

Configuration

The server is configured via environment variables:

• VAULT_ADDR: The Vault server address (default: http://127.0.0.1:8200)
• VAULT_TOKEN: The Vault authentication token (required)

Configuration files are located in the configs/ directory:

• configs/vault-catalog.yaml - Docker Desktop MCP Toolkit catalog configuration
• configs/mcp_config.json - MCP client configuration (Cursor, Claude Desktop)

Available Tools

vault_read

Read a secret from Vault.

Parameters:

• path (string, required): The path to read the secret from (e.g., secret/data/myapp)

Example:

{
  "path": "secret/data/myapp"
}

vault_write

Write a secret to Vault.

Parameters:

• path (string, required): The path to write the secret to (e.g., secret/data/myapp)
• data (object, required): The secret data to write as a JSON object

Example:

{
  "path": "secret/data/myapp",
  "data": {
    "username": "admin",
    "password": "secret123"
  }
}

vault_list

List secrets at a path in Vault.

Parameters:

• path (string, required): The path to list secrets from (e.g., secret/metadata)

Example:

{
  "path": "secret/metadata"
}

vault_delete

Delete a secret from Vault.

Parameters:

• path (string, required): The path to delete the secret from (e.g., secret/data/myapp)

Example:

{
  "path": "secret/data/myapp"
}

Development

Local Development Setup

# Install dependencies
npm install

# Build the project
npm run build

# Run locally (requires Vault server)
VAULT_ADDR=http://localhost:8200 VAULT_TOKEN=myroot npm start

Project Structure

vault-mcp/
├── .github/
│   └── workflows/
│       └── docker-build-publish.yml  # CI/CD workflow for container builds
├── configs/              # MCP configuration files
│   ├── mcp_config.json   # MCP client configuration (Cursor, Claude Desktop)
│   └── vault-catalog.yaml # Docker Desktop MCP Toolkit catalog
├── docs/                 # Documentation files
├── src/
│   └── index.ts          # Main MCP server implementation
├── dist/                 # Compiled JavaScript (generated)
├── Dockerfile           # Container definition
├── docker-compose.yml   # Docker Compose configuration
├── package.json         # Node.js dependencies
├── setup.ps1            # Setup script for Windows (PowerShell)
├── setup.sh             # Setup script for macOS/Linux (Bash)
├── tsconfig.json        # TypeScript configuration
└── README.md           # This file

CI/CD

The project uses GitHub Actions to automatically build and publish Docker images:

• On push to main: Builds and publishes the latest tag and a SHA-based tag
• On pull request: Builds the image to verify it compiles (does not publish)
• On version tags (e.g., v1.0.0): Builds and publishes version-specific tags (e.g., v1.0.0, v1.0, v1)

Images are published to GitHub Container Registry at ghcr.io/kelleyblackmore/vault-mcp.

Security Considerations

• Never hardcode Vault tokens in configuration files
• Use appropriate Vault policies to limit MCP server permissions
• For production use, replace the dev Vault server with a properly configured production instance
• Consider using Vault AppRole or Kubernetes auth instead of token-based auth
• Use secrets management tools to inject VAULT_TOKEN at runtime

License

MIT
