Julia Plotting Playground

A minimal, extensible repository showcasing plotting in Julia using Plots.jl. The repository currently includes line plots and histograms via line.jl and histogram.jl. Future extensions can be added as new plot modules (e.g., pie charts, scatter plots, etc.).

Built with Julia, Plots.jl, and selectable rendering backends (GR / PythonPlot).

---

• About this repository
• Install Julia and plotting packages
• Why the first run can take “couple of minutes”
• Running with VS Code (recommended)
• Running without VS Code (Terminal / cmd / Git Bash)
• Outputs (where images are saved)
• Line plots module (line.jl)
• Histogram plots module (histogram.jl)
• Implementation tutorial video

---

About this repository

This repository is a small, practical starting point for plotting in Julia using Plots.jl.

Current examples:

• line.jl — multiple line-plot demonstrations (multi-series plots, markers, subplots, tiled layouts, and a CSV-driven plot).
• histogram.jl — a histogram “toolbox” (binning rules, normalization, categorical histograms, overlays, and a CSV-driven histogram).

---

Install Julia and plotting packages

1) Install Julia

Install Julia 1.10+ (this repository was developed with Julia 1.12.x).

Recommended approach:

• Install Julia from the official Julia downloads page.
• Ensure the julia executable is available from your terminal.

Quick verification (any terminal):

julia --version

If a version prints, Julia is installed correctly.

---

2) Install packages in Julia (Pkg)

Julia uses Pkg (its built-in package manager). For this repository, you will install the plotting stack once, and then run the scripts.

From the Julia REPL (run this in the repo root folder):

julia
julia> import Pkg
julia> Pkg.activate(".")
julia> Pkg.add(["Plots","StatsBase","CSV","DataFrames","Downloads","PythonPlot"])

What this does:

• Pkg.activate(".") creates/uses a project environment in the current folder (the repo root).
• Pkg.add(...) installs the required packages into that environment.
• As a side effect, Julia generates (or updates) the environment files:
  • Project.toml (direct dependencies)
  • Manifest.toml (locked dependency graph)

This repository does not include Project.toml, Manifest.toml, or .vscode/ by design (to avoid machine-specific paths and to keep the repo lightweight). You generate them locally using the steps above.

---

3) Dependencies used in this repository

The scripts use these packages and standard libraries:

• Plots — main plotting interface.
• GR — commonly used rendering backend (selected with gr()).
• PythonPlot — optional backend (selected with pythonplot()).
• StatsBase — histogram utilities (counting, bin rules, etc.).
• CSV + DataFrames — reading and manipulating tabular datasets.
• Downloads — downloading CSV files directly from URLs.
• Standard libraries: Random, Statistics.

Backend note:

• If you use pythonplot(), Julia may create a Python environment (via PythonCall/CondaPkg) the first time you run it.

---

Why the first run can take “couple of minutes”

It is normal (especially on Windows) for the first run of a plotting repository to take a long time.

This is typically caused by a combination of:

1. Package downloads
   On first use, Julia downloads the packages you added via Pkg.add(...).

2. Artifact downloads (binary dependencies)
   Plotting stacks commonly require binary artifacts (e.g., GR runtime, fonts, image/video encoders). Julia downloads these artifacts the first time they are needed.

3. Precompilation (JIT + caching)
   Julia compiles package code into cached .ji files. Plotting packages are large, so precompilation can be substantial.

4. Backend initialization

   • With gr(), the GR runtime is initialized and cached.
   • With pythonplot(), Julia may also download and configure a Python distribution and dependencies (via CondaPkg / MicroMamba).

After this initial setup, future runs are typically much faster because packages, artifacts, and compiled caches are already present.

Practical advice:

• Run the package installation steps once, then run scripts normally.
• If the first run is slow, it is usually doing real work (downloads/precompile) rather than being stuck.

---

Running with VS Code (recommended)

This repository supports a clean workflow in Visual Studio Code using the Julia extension.

1) Install VS Code and the Julia extension

• Install Visual Studio Code.
• Install the Julia extension (by the Julia VS Code team).

2) Open the repository folder

In VS Code:

• File → Open Folder… → select the repo directory (where line.jl and histogram.jl exist).

3) Create the Julia environment for this repo

1. Open the Julia REPL inside VS Code

• Press Ctrl + Shift + P to open the Command Palette
• Type: Julia: Start REPL
• Press Enter

You should now see a Julia REPL terminal open inside VS Code.

2. Activate the repo environment and install dependencies In the Julia REPL, first make sure the working folder is the repository root (the folder you opened in VS Code). Then run:

import Pkg
Pkg.activate(".")
Pkg.add(["Plots","StatsBase","CSV","DataFrames","Downloads","PythonPlot"])

What you should expect:

• Julia creates/updates Project.toml and Manifest.toml in the repo folder (locally on your machine).
• All required packages are installed into that environment.
• The first install may take a while because Julia is downloading and precompiling packages.

---

4) IMPORTANT: Ensure VS Code is using the repo environment (fixes “StatsBase not found”)

If you can run line.jl but histogram.jl fails with:

• ArgumentError: Package StatsBase not found in current path
• or you see output like Activating project at C:\...\ .julia\environments\v1.7

then VS Code is running your file in the global default environment (e.g., ~/.julia/environments/v1.7) instead of the repo environment you created in this folder.

Use the checks and fixes below.

A) Quick check (in the VS Code Julia REPL)

Run:

import Pkg
Base.active_project()

Expected result:

• The printed path should point to the repo, e.g. <your-repo>\Project.toml.

If you instead see something like:

• C:\Users\...\ .julia\environments\v1.7\Project.toml

then the repo environment is not active for your current VS Code session.

B) Activate the repo environment in VS Code

Option 1 (recommended): activate via the command palette

• Press Ctrl + Shift + P
• Run: Julia: Activate This Environment
• Select the repository folder (the folder that contains Project.toml)

Option 2: activate in the REPL

import Pkg
Pkg.activate(".")

C) Make sure VS Code is using the correct Julia version

If VS Code is launching Julia 1.7 (and activating v1.7), but you installed Julia 1.10+ separately, configure the Julia extension to use the newer executable:

• VS Code → command palette (ctrl + shift + p) → Settings → search for Julia: Executable Path
• Point it to your Julia 1.10+ julia.exe

You can verify the current Julia version in the VS Code REPL:

versioninfo()

---

5) Configure VS Code run settings (launch.json) to use the repo environment

Option A (UI-driven, recommended)

1. Open the Run and Debug panel (left sidebar)
2. Click Create a launch.json file
3. If prompted to select an environment, choose Julia
4. Select a template such as:
   • Run active Julia file

Then verify (or adjust) that:

• the script is the active editor file (${file})
• the working directory is the repo folder (${workspaceFolder})
• the environment used is the repo environment (points to ${workspaceFolder})

Option B (manual) — copy/paste launch.json (recommended if you want Ctrl+F5)

1. In the repo root, create a folder named:

.vscode

2. Inside .vscode/, create a file named:

launch.json

3. Paste the following exact content into .vscode/launch.json:

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "julia",
      "request": "launch",
      "name": "Run active Julia file (repo env)",
      "program": "${file}",
      "cwd": "${workspaceFolder}",
      "juliaEnv": "${workspaceFolder}"
    }
  ]
}

What this configuration does:

• Runs the currently active file (e.g., line.jl or histogram.jl) via "program": "${file}"
• Sets the working directory to the repo root via "cwd": "${workspaceFolder}"
• Forces the Julia environment to be the repo environment via "juliaEnv": "${workspaceFolder}"

If you already have a launch.json created by VS Code, make sure it includes the two key lines above:

• "cwd": "${workspaceFolder}"
• "juliaEnv": "${workspaceFolder}"

---

6) Run the scripts

Run line.jl

1. Open line.jl in the editor
2. Press Ctrl + Shift + P
3. Type: Julia: Execute Active File
4. Press Enter

Run histogram.jl

1. Open histogram.jl in the editor
2. Press Ctrl + Shift + P
3. Type: Julia: Execute Active File
4. Press Enter

The scripts save PNG outputs (see the outputs section below).

Troubleshooting: StatsBase not found when running histogram.jl

If line.jl runs but histogram.jl fails with Package StatsBase not found, it means the file is being executed in an environment that does not have StatsBase installed (most commonly the global ~/.julia/environments/v1.x environment).

Fix (recommended): activate the repo environment, then install dependencies there:

import Pkg
Pkg.activate(".")
Pkg.add(["Plots","StatsBase","CSV","DataFrames","Downloads","PythonPlot"])

Quick workaround (not recommended long-term): install StatsBase into the currently active environment:

import Pkg
Pkg.add("StatsBase")

How to run with Ctrl + F5 (Run Without Debugging)

• Open line.jl or histogram.jl
• Press Ctrl + F5
• VS Code will run the active Julia file using the configuration above

Notes:

• Ctrl + F5 works reliably when:
  • the Julia extension is installed
  • the .vscode/launch.json exists
  • you opened the repo folder (not just a single .jl file)
• If VS Code asks which configuration to use, select:
  • Run active Julia file (repo env)
• If you see Activating project at ...\.julia\environments\v1.x, re-check the environment activation section above and confirm you are using the repo environment.

Optional (but strongly recommended):

• Run the environment setup once (in the VS Code Julia REPL):

import Pkg
Pkg.activate(".")
Pkg.add(["Plots","StatsBase","CSV","DataFrames","Downloads","PythonPlot"])

This ensures the repo environment exists before you start using Ctrl+F5.

---

Running without VS Code (Terminal / cmd / Git Bash)

You can run everything using a terminal only.

1) One-time package install (creates the repo environment files locally)

From the repository root, open Julia and run:

julia
julia> import Pkg
julia> Pkg.activate(".")
julia> Pkg.add(["Plots","StatsBase","CSV","DataFrames","Downloads","PythonPlot"])

This installs dependencies and generates Project.toml and Manifest.toml locally.

2) Run line plots

From the repository root:

include("line.jl")

3) Run histograms

From the repository root:

include("histogram.jl")

---

Outputs (where images are saved)

Both scripts save figures to image files (PNG).

• Output location: by default, the current working directory at runtime.
  • In terminal runs, this is usually the repo root (unless you cd elsewhere).
  • In VS Code runs, it is usually the workspace folder.

If you want outputs in a dedicated folder, a common pattern is:

• Create output/
• Change savefig(..., "output/plot.png")

---

Line plots module (line.jl)

This section documents the line plot examples implemented in line.jl.
It is structured to be modular so you can add future plot modules without rewriting the README layout.

Imports and backend selection

Key imports at the top of line.jl:

• using Plots — plotting interface
• using Random, Statistics — data generation and statistics
• using CSV, DataFrames, Downloads — CSV download + reading
• pythonplot() — selects the PythonPlot backend for Plots.jl (an alternative is gr())

The file also sets a global default:

• default(dpi=300) makes saved figures high resolution by default.

Helper function: GitHub “blob” link → “raw” link

github_blob_to_raw(url) converts URLs like:

• https://github.com/.../blob/.../file.csv

into:

• https://raw.githubusercontent.com/.../.../file.csv

This is necessary because CSV readers must download the raw file contents, not the GitHub HTML page.

What line.jl generates

The script contains multiple independent blocks (begin ... end). Each block builds a plot and saves a PNG file.

1) Multiple line plots on the same axes → line_1.png

• Uses LinRange(0, 2π, 200) to create a dense x-axis.
• Computes sin.(x) (broadcasted sin).
• Overlays multiple series using plot!:
  • sin(x)
  • -sin(x)
  • x/π - 1
  • a manually defined series with implicit x = 1:n
• Demonstrates line styles and markers.

2) Plot from a collection of vectors → line_2.png

• Builds a Set of Vector{Float64} values.
• Iterates and calls plot! for each vector.
• Demonstrates plotting “container of containers” where each vector becomes a separate series.

3) Sin function line plots with phase shifts → line_3.png

• Plots sin(x) and phase-shifted versions sin(x - 0.25) and sin(x - 0.5).
• Uses different line styles for clarity.

4) Sin function line plots with markers → line_4.png

• Similar to (3) but emphasizes marker styles:
  • circles, stars, and different line styles.

5) Simple tiled layout (2×1) → line_5.png

• Creates two separate plots (p_top, p_bot) and combines them with:
  • plot(p_top, p_bot; layout=(2, 1))

This is a stacked subplot arrangement in Plots.jl.

6) 3×2 subplots in a single figure → line_6.png

Creates a 3×2 grid with six subplots:

• (0,0) sin(x) with marker indices using scatter!
• (0,1) tan(sin(x)) - sin(tan(x)) with custom style settings
• (1,0) cos(5x) with labels and title
• (1,1) a “time plot” with custom xticks labels like "00:00s", "01:00", etc.
• (2,0) sin(5x)
• (2,1) a parametric circle with aspect_ratio=:equal to avoid distortion

7) Plot from a CSV dataset (download + scatter + line) → line_csv.png

• Downloads an Iris dataset CSV from a URL.
• Reads it using CSV.read(..., DataFrame).
• Automatically selects numeric columns and uses the first two numeric columns as x/y.
• Sorts by x so the line overlay is well-behaved.
• Produces a scatter plot with a line overlay.

Extending the line module

If you add new line examples, keep the structure consistent:

• one begin ... end block per figure
• a deterministic output filename (savefig(..., "line_N.png"))

---

Histogram plots module (histogram.jl)

This section documents the histogram examples implemented in histogram.jl.
It is structured to be modular so you can add future distribution-plot or histogram variants easily.

Imports and plotting defaults

Key imports:

• using Plots — histogram and bar plotting
• using StatsBase — histogram utilities such as countmap, and statistical helpers
• using Random, Statistics — data generation and descriptive stats
• using CSV, DataFrames, Downloads — CSV download + reading

Backend selection and defaults:

• gr() selects the GR backend.
• default(...) sets high-quality global plot parameters:
  • dpi, size, framestyle, grid
  • font sizes, line widths, margins, etc.

A helper saveplot(plt, filename) wraps savefig and prints absolute file paths for convenience.

Helper functions (core logic)

1) github_blob_to_raw(url)

Ensures downloads fetch raw file content rather than HTML pages.

2) assert_looks_like_csv(path)

Checks the first bytes of a downloaded file. If the file looks like HTML (e.g., a 404 page), it throws an error immediately. This prevents confusing downstream CSV parsing errors.

3) make_edges(x, rule; maxbins=200)

Builds explicit histogram bin edges using common rules:

• :sturges — Sturges’ rule
• :sqrt — √n bins
• :scott — Scott’s normal reference rule
• :fd / :auto — Freedman–Diaconis style rule (robust via IQR)
• :integers — integer-aligned bins (useful for discrete integer data)

It also includes practical safeguards:

• avoids division-by-zero problems (e.g., zero variance data)
• caps bin count using maxbins to prevent pathological over-binning

4) choose_numeric_column(df)

A heuristic for selecting a “good” numeric column from a real dataset:

• prefers meaningful column names if present (e.g., :price, :carat, etc.)
• excludes index-like columns (id, index, unnamed, row)
• tries to avoid monotone unique columns (often row IDs)
• otherwise selects the numeric column with the largest variance

What histogram.jl generates

Each block produces an output image file.

1) Simple histogram of standard normal data → histogram_1.png

• Generates randn(10_000)
• Uses make_edges(..., :auto)
• Saves a standard frequency histogram

2) Compare different binning rules → histogram_2.png

Creates a 2×3 grid comparing:

• Auto
• Scott
• FD
• Integers
• Sturges
• Sqrt

3) Dynamic bin count demo → histogram_3.png (manual bins example saved)

• Demonstrates recomputing edges and updating titles.
• Shows an example with a fixed “50 bins” edge range and saves it.

4) Custom edges + density normalization → histogram_4.png

• Provides explicit bin edges
• Uses normalize=:density so bar heights represent count density

5) Categorical “histogram” via bar plot → histogram_5.png

• Counts string category labels using countmap
• Sorts levels
• Plots counts via bar(...)

6) Overlay normalized histograms → histogram_6.png

• Generates two distributions with different means/sample sizes
• Uses a shared edge vector for meaningful comparison
• Uses normalize=:probability so each histogram sums to 1
• Overlays using histogram!

7) Histogram as PDF + theoretical normal curve → histogram_7.png

• Uses normalize=:pdf so the histogram approximates a probability density function
• Defines a normal PDF function and overlays it using plot!

8) Histogram from CSV dataset → histogram_csv.png

• Downloads a diamonds dataset CSV
• Validates it looks like CSV (not HTML)
• Reads into a DataFrame
• Chooses a numeric column robustly using choose_numeric_column
• Builds edges using FD rule with a bin cap (maxbins=120)
• Prints dataset summary statistics (n, min, max, mean, std)

Extending the histogram module

To add new histogram examples, follow the same pattern:

• one begin ... end block per figure
• save with deterministic filenames (histogram_N.png)
• keep helper functions reusable to avoid duplication

---

Implementation tutorial video

At the end of the workflow, you can watch the full implementation and walkthrough on YouTube.
