Fresh Install of 8.7.2 missing images folder.

[james7342]

Just installed the NBrightData_8.7.2_Install on a test site followed by OpenStore_4.1.11_Install. Upon opening the OpenStore Backoffice Page Admin/Settings some images are missing on the page. Path to image is "/DesktopModules/NBright/NBrightBuy/images/flags/en-US.gif".

[james7342]

Actually looking at this some more, it might be more of a template issue and the path is incorrect. I changed in the browser inspector and the images loads correct if I use the path from the top bar upper right flag path.

[james7342]

Since OpenStore requires both modules I hope I opened this issue on the correct project.

[DNNMonster]

It sounds like a template issue but I have not seen it before... I run custom templates so I may not have noticed if there was a bug introduced into the default template flag images. Is it persisting after you save your Store settings, clear the cache and do a application restart?

[james7342]

I was looking in the OpenStore GitHub repo and found this closed issue.
openstore-ecommerce/OpenStore#200

Seems to be related and possible not a NBrightTS Issue.

[james7342]

It sounds like a template issue but I have not seen it before... I run custom templates so I may not have noticed if there was a bug introduced into the default template flag images. Is it persisting after you save your Store settings, clear the cache and do a application restart?

Yes.

[DNNMonster]

Sure sounds like something is amiss in the BO template then. If you have no luck identifying it then I can try to test against a fresh install but it may not be for at least a few days. Let's tap @leedavi to see if he hasn't already identified this issue.

[james7342]

I think I may have found it. I don't have a development environment setup to test a change in though. I think it's in the GenXmlTemplateExt.cs

private void CreateEditFlag(Control container, XmlNode xmlNod) { var lc = new Literal(); var size = "16"; if (xmlNod.Attributes != null && (xmlNod.Attributes["size"] != null)) size = xmlNod.Attributes["size"].Value; lc.Text = "<img 'langflag' src='" + **StoreSettings.NBrightBuyPath()** + "/images/flags/" + StoreSettings.Current.EditLanguage + ".gif' />"; lc.DataBinding += EditFlagDataBind; container.Controls.Add(lc); }

Looking through the source code this is the only file that has the StoreSettings.NBrightBuyPath() in the path with a 'langflag'.
This is what is rendered in the BO page when viewing inspecting the page.
<img 'langflag'="" src="/DesktopModules/NBright/NBrightBuy/images/flags/en-US.gif">

[DNNMonster]

Ok.. I think I may caused the problem with this commit openstore-ecommerce/OpenStore@3db925b. If you can share the url of the image that is working for you I suspect it will confirm that the issue is a missing size directory and that the image that is working for you is a .png and not a .gif...??? If you can confirm that this is the problem then I will go ahead and roll back the changes.

[james7342]

Looking in the EditLanguage.ascx.cs the path looks like this:
<img 'langflag' src='/images/flags/" + l.Value.Code + ".gif' alt='" + l.Value.EnglishName + "' />

But in the GenXmlTemplateExt.cs file the path is this:
<img 'langflag' src='" + StoreSettings.NBrightBuyPath() + "/images/flags/" + StoreSettings.Current.EditLanguage + ".gif' />

I think in the GenXmlTemplate file if the path was updated to match the one in EditLanguage my thought is that should fix it.

The file is a GIF and not PNG.

I'll open a separate one for the bootstrap.css.map file 404. I know they're not needed but referenced in the project and causing the 404 error.
